(4) Place hood in position on vehicle. With assis- tance from a helper at the opposite side of the vehicle (5) Install cowl plenum grille (Refer to 23 - BODY/ EXTERIOR/COWL GRILLE - INSTALLATION). (6) When installing hood, align all marks and secure bolts. The hood should be aligned. (Refer to 23 (7) Verify hood operation and alignment. lbs.). (9) Tighten hinge to hood bolts to 14 N·m (120 in. lbs.). (10) Close hood. hood operation. HOOD REMOVAL (1) Raise hood to full up position (Fig. 4). with a grease pencil or other suitable device to pro- (3) Remove the top bolts attaching hood to hinge and loosen the bottom bolts until they can be (4) With assistance from a helper at the opposite side of the vehicle to support the hood, remove bot- (5) Remove the hood from the vehicle. INSTALLATION (1) Place hood in position on vehicle. With assis- tance from a helper at the opposite side of the vehicle (2) Install top bolts attaching hood to hinge finger tight. (3) When installing hood, align all marks and secure bolts. The hood should be aligned. (Refer to 23 (4) Verify hood operation and alignment. HOOD SEAL REMOVAL (1) Open hood. gage the hood seal push pins from the hood. INSTALLATION (1) Place hood seal into position (Fig. 6). tion in hood. (3) Close hood. Fig. 5 HOOD HINGE LOWER HALF 1 - HOOD HINGE LOWER HALF Fig. 6 HOOD SEAL 1 - HOOD INNER PANEL CS HOOD 23 - 71 HINGE (Continued) |
