Chevrolet Silverado / GMC Sierra. Manual - part 2256

FRONT SIDE DOOR EMBLEM/NAMEPLATE REPLACEMENT (GMC SIERRA)

Fig. 7: View Of Door Emblem and Nameplate (GMC Sierra)
Courtesy of GENERAL MOTORS CORP.

prior to installing new nameplate.

3. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

4. Close the door prior to installing the new nameplate/emblem to the door.

5. Remove the protective liner from the back side of the adhesive tape.

6. Align the nameplate/emblem to the door and press to ensure full adhesion is made to

the door.

Callout

Component Name

Front Side Door Nameplate/Emblem (Sierra)



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 8

© 2005 Mitchell Repair Information Company, LLC.

FRONT SIDE DOOR EMBLEM/NAMEPLATE REPLACEMENT (CHEVROLET SILVERADO)

1


Tip:

1. The part and surface should be 21°C (70°F) prior to installation. The vehicle should

remain 21°C (70°F) for one hour after assembly to allow adhesive to develop
sufficient bond strength.

2. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. Clean all the

adhesive residue from the door and wipe the surface dry with a clean lint-free towel
prior to installing new nameplate.

3. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

4. Close the door prior to installing the new nameplate/emblem to the door.

5. Remove the protective liner from the back side of the adhesive tape.

6. Align the nameplate/emblem to the door and press to ensure full adhesion is made to

the door.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 9

© 2005 Mitchell Repair Information Company, LLC.

Fig. 8: View Of Door Emblem and Nameplate (Chevrolet Silverado)
Courtesy of GENERAL MOTORS CORP.

Callout

Component Name

1

Front Side Door Nameplate/Emblem (Silverado)


Tip:

1. The part and surface should be 21°C (70°F) prior to installation. The vehicle should

remain 21°C (70°F) for one hour after assembly to allow adhesive to develop
sufficient bond strength.

2. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. Clean all the

adhesive residue from the door and wipe the surface dry with a clean lint-free towel
prior to installing new nameplate.

3. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or

NOTE:

Refer to Exterior Trim Emblem Removal Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 10

© 2005 Mitchell Repair Information Company, LLC.

FRONT SIDE DOOR EMBLEM/NAMEPLATE REPLACEMENT (GMC DENALI)

Fig. 9: View Of Door Emblem and Nameplate (GMC Denali)
Courtesy of GENERAL MOTORS CORP.

any foreign matter prior to adhesion.

4. Close the door prior to installing the new nameplate/emblem to the door.

5. Remove the protective liner from the back side of the adhesive tape.

6. Align the nameplate/emblem to the door and press to ensure full adhesion is made to

the door.

Callout

Component Name

Front Side Door Nameplate/Emblem (Denali)


Tip:

1. The part and surface should be 21°C (70°F) prior to installation. The vehicle should

NOTE:

Refer to Exterior Trim Emblem Removal Notice .
