23– 27 23 Front Stabilizer Link Assembly Removal HINT: Use the same procedures for the right side and left side. Procedures listed below are for the left side. 2. Remove the front left stabilizer link assembly. a. Hold the lower end of front left stabilizer link assembly with an inner hexagon wrench, and remove the (Tightening torque: 45 ± 5 N·m) b. Hold the upper end of front left stabilizer link assembly with an inner hexagon wrench, and remove the (Tightening torque: 45 ± 5 N·m) c. Remove the front left stabilizer link assembly. Inspection 1. Check front stabilizer link assembly. a. Check front stabilizer link assembly bushes for wear, cracks, deformation, damage or grease leakage. Replace as necessary. b. Check if the end of front stabilizer link assembly rotates smoothly. Replace as necessary. CAUTION Be sure to wear necessary safety equipment to prevent accidents. RT21230240 RT21230031 |
