Chery IndiS (S18D) . Manual - part 11

1.4. Remove the lower cover of instrument panel

(avoid the break of the two clips in inner side)

1.5. Remove the two fixing screws connecting the

dashboard and instrument panel body with
cross screwdriver.

1.6. Pry out the dashboard body with slotted

screwdriver.

1.7. Pull off the harness connector on instrument

panel body and remove it.

1.8. Pry out the dashboard brightness adjusting

switch with slotted screwdriver.

1.9. Screw off the fixing nut of engine hood handle

and remove the handle and cable. (See the
removal and installation procedures of engine
hood handle and cable)

1.10.

Pry out the central control panel shield
with slotted screwdriver.

1.11.

Pull off the A/C regulating switch harness
and central control panel switch harness.

Note: during installation, notice the color marked
by the harness shall be correspond to the color of
the connector on switch back, wrong installation is
not allowed.

1.12.

Remove the fixing screw of radio
cassette player.

1.13.

Pull off the harness and antenna
connector of radio cassette player,
remove the radio cassette player.

1.14.

Loosen the two bolts besides the name
car box with 10# socket wrench.

1.15.

Pry out the speaker shield with slotted
screwdriver.

1.16.

Remove the speaker body with slotted
screwdriver.

1.17.

Remove the two screws on pillar-A lower
panel with cross screwdriver, remove the
pillar-A lower panel.

1.18.

Remove the fixing bolt of instrument
panel body and hinge inner side sheet
metal with 10# socket wrench.

1.19.

Remove the panel on two sides of
instrument panel body.

1.20.

Remove the fixing screws on two sides of
instrument panel body with cross
screwdriver.

1.21.

Remove   the   fixing   bolt   between   body
sheet   metal   and   the   instrument   panel
body   beside   speaker   with   10#   socket
wrench.

1.22.

Remove the instrument panel body.
