HYDRAULIC PUMP (Cont’d) Removal And Installation When making repairs on hydrostatic and I–2003–0284 Raise the operator cab. (See Page 1–1.) Drain the hydraulic reservoir. (See Page 1–1.) Disconnect the hose (Item 1) [A] from the pump outlet. Disconnect the tubeline from the inlet of the pump [A]. Remove the mump mounting bolts [B]. Remove the hydraulic pump [C]. Always clean up spilled fuel or oil. Keep heat, W–2103–1285 NOTE: The hydraulic pump is shown being removed with the hydrostatic pump/engine assembly Never work on a machine with the lift arms up W–2059–0598 A CD–10950 1 C P–04857 853, 853H BICS Loader –2–37– Service Manual B CD–10951 |
