OPERATOR CAB GAS CYLINDER (Cont’d) Removal And Installation (Cont’d) Move the mounting bracket forward to relieve any Remove the retainer pin (Item 1) [B] from the top pivot Remove the pivot pin and bushing from the gas cylinder. Remove the gas cylinder. NOTE: Lift arms are raised for photo clarity. Disassembly And Assembly Remove the clevis (Item 1) [C] and washer (Item 2) [C] Remove the gas cylinder from the outer housing. Assembly: Install a replacement cylinder inside the Apply a small amount of LOCTITE on the threads of the Reinstall the washer and clevis on the cylinder rod. A N–00823 C P–01008 2 1 D P–01006 –5–12– 773 BICS Loader Service Manual B N–00841 1 |
