HYDROSTATIC DRIVE MOTOR (Cont’d) Disassembly And Assembly (S/N 509639898 & Below Remove the O–rings inside the bore of the mounting The bushing is a guide to center the motor on the Drill several holes in the bushing [B]. Use a chisel and hammer, remove the bushing from the Use a hydraulic press to install the new bushing. Assembly: When installing the balance plate in the end NOTE: Always use new O–rings, gaskets and seals when assembling the hydrostatic motor. D B–08690 A B–04636 C B–09470 –3–20– 773 BICS Loader Service Manual B B–09469 |
