53

Aerial system with switched diversity

Aerial

Function

Aerial amplifier

R24

Analogue radio aerial amplifier (FM1, AM)
Central locking aerial amplifier

Radio/telephone/navigation aerial R52

Telephone aerial, navigation aerial
Digital satellite radio aerial (SDARS, North America only)

Aerial amplifier 2

R111

Analogue radio aerial amplifier (FM2)
TV aerial amplifier -1-
TV aerial amplifier -2-

with switched diversity only:
Analogue radio aerial amplifier (FM3, FM4, Diversity)

Aerial amplifier 4

R113

TV aerial amplifier -3-
TV aerial amplifier -4-
Digital terrestrial radio aerial amplifier (DAB)

382_026

R52

Telephone

R113

R24

R111

Central locking

TV3

SDARS SAT

SDARS Terr.

Radio IF

TV2
TV1

FM

 r

e

ject

or ci

rcuit

 c

h

oke +

FM r

e

je

ct

or circu

it c

h

oke -

Navigation

FM1 / AM

DAB / TV4

Radio HF

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

54

Notes

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

Self-Study Programme 382 describes the new
features of the convenience electronics in the
Audi TT Coupé ‘07. The proven electronic
technology of the Audi A3 ‘04 has been adopted for
the TT Coupé. The most striking new feature is the
automatic extending rear spoiler activated by the
convenience system central control unit.

In the TT Coupé, the driver information system (DIS)
in the centre display of the dash panel insert has an
extended settings and query menu.
The customer can use the settings menu to
configure functions and make adjustments. This
was previously possible only in vehicles with MMI.

The Audi TT Coupé ‘07 offers the customer
a multitude of functions and equipment options,
with the result that the number of control units has
increased considerably compared to the
predecessor model.
To ensure smooth interaction between control units,
the control units communicate with one another
across various bus systems.
The networking structure is largely identical to that
of the Audi A3 `04. In this self-study programme you
will be informed about the network topology of the
TT Coupé and about the installation locations of the
various control units as well as their functions.

The Audi TT Coupé ‘07 comes with new generation
2plus radios. The radios feature a new reception
concept as well as
MP3 compatible CD drives.
The TT Coupé, as do the Audi A3 and A4, comes with
a BNS 5.0 radio navigation system with MMI user
interface and CD navigation.
The BOSE Surround Sound system, which includes
12 loudspeakers driven by a 255 watt amplifier, sets
new standards in this vehicle class.

Innovations in the electronics, electrical and infotainment
systems in the Audi TT Coupé ‘07

Excellence in design & performance

Self-study programmes on the TT Coupé

382_014

382_044

382_032

SSP 381 Audi TT Coupé ‘07 -
Suspension System

–

Front  axle

–

Rear  axle

–

Shock absorber system

–

Brake system

Order number: A06.5S00.26.20

SSP 382 Audi TT Coupé ‘07 -
Electrical and Infotainment Systems

–

Networking

–

Bus  topology

–

Convenience electronics

–

Infotainment

Order number: A06.5S00.27.20

SSP 380 Audi TT Coupé ‘07

–

Body

–

Occupant protection

–

Engine

–

Suspension system

–

Electrical system

–

Air conditioning

–

Infotainment

Order number: A06.5S00.25.20

SSP 383 Audi TT Coupé ‘07 - Body

–

Audi Space Frame

–

Production processes and joining methods

–

Surface  finish

–

Electromechanical rear spoiler

–

Repair concept

–

Passive safety concept

Order number: A06.5S00.28.20
