Audi TT Coupé ‘07 -
Electrical and Infotainment Systems

Self-Study Programme 382

Vorsprung durch Technik www.audi.de

Service Training

Self-Study Programme 382 describes the new
features of the convenience electronics in the
Audi TT Coupé ‘07. The proven electronic
technology of the Audi A3 ‘04 has been adopted for
the TT Coupé. The most striking new feature is the
automatic extending rear spoiler activated by the
convenience system central control unit.

In the TT Coupé, the driver information system (DIS)
in the centre display of the dash panel insert has an
extended settings and query menu.
The customer can use the settings menu to
configure functions and make adjustments. This
was previously possible only in vehicles with MMI.

The Audi TT Coupé ‘07 offers the customer
a multitude of functions and equipment options,
with the result that the number of control units has
increased considerably compared to the
predecessor model.
To ensure smooth interaction between control units,
the control units communicate with one another
across various bus systems.
The networking structure is largely identical to that
of the Audi A3 `04. In this self-study programme you
will be informed about the network topology of the
TT Coupé and about the installation locations of the
various control units as well as their functions.

The Audi TT Coupé ‘07 comes with new generation
2plus radios. The radios feature a new reception
concept as well as
MP3 compatible CD drives.
The TT Coupé, as do the Audi A3 and A4, comes with
a BNS 5.0 radio navigation system with MMI user
interface and CD navigation.
The BOSE Surround Sound system, which includes
12 loudspeakers driven by a 255 watt amplifier, sets
new standards in this vehicle class.

Innovations in the electronics, electrical and infotainment
systems in the Audi TT Coupé ‘07

Excellence in design & performance

Self-study programmes on the TT Coupé

382_014

382_044

382_032

SSP 381 Audi TT Coupé ‘07 -
Suspension System

–

Front axle

–

Rear axle

–

Shock absorber system

–

Brake system

Order number: A06.5S00.26.20

SSP 382 Audi TT Coupé ‘07 -
Electrical and Infotainment Systems

–

Networking

–

Bus topology

–

Convenience electronics

–

Infotainment

Order number: A06.5S00.27.20

SSP 380 Audi TT Coupé ‘07

–

Body

–

Occupant protection

–

Engine

–

Suspension system

–

Electrical system

–

Air conditioning

–

Infotainment

Order number: A06.5S00.25.20

SSP 383 Audi TT Coupé ‘07 - Body

–

Audi Space Frame

–

Production processes and joining methods

–

Surface finish

–

Electromechanical rear spoiler

–

Repair concept

–

Passive safety concept

Order number: A06.5S00.28.20

Note

Reference

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Topology and networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation overview - control units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Fuses and relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

The self-study programme teaches the design and function of new vehicle models,
new automotive components or new technologies.

The self-study programme is not a repair manual!
All values given are intended as a guideline only, and refer
to the software version valid at the time of publication of the SSP.

For maintenance and repair work, always refer to the current technical literature.

Contents

Infotainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chorus, concert and symphony radios in 2-DIN housing  . . . . . . . . . . . . . . . . . . 36
MP3 basics - ID3 day . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Audi Navigation (BNS 5.0). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Sound systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Apple iPod adaptor  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Aerials  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Electrical system and convenience electronics . . . . . . 10

Data bus diagnostic interface J533 (gateway). . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control unit with display in dash panel insert J285 . . . . . . . . . . . . . . . . . . . . . . . 13
Onboard power supply control unit J519 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Front outside light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Rear outside light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Convenience system central control unit J393 . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Parking aid control unit J446. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Overview

Topology and networking

Engine control unit

J623

Direct shift gearbox

mechatronics

J743

Selector lever

E313

ABS control unit

J104

Airbag control unit

J234

Four-wheel drive

control unit

J492

Tyre pressure

monitor control unit 2

J793*

Power steering

control unit

J500

Steering angle

sender

G85

Steering column

electronics control

unit

J527

Multi-function

steering wheel control

unit

J453

ECD control unit

(electronically

controlled damping)

J250

Headlight range

control, control unit

J431

Power output module

for left headlight

J667

Power output module for

right headlight

J668
