Audi TT Coupé ‘07

Self-Study Programme 380

Vorsprung durch Technik www.audi.de

Service Training

Introduction

The first generation of the Audi TT Coupé, named after the legendary "Tourist Trophy" race in the UK, was
a milestone in automotive design.
The design followed the pure geometry, with central motives being the circle, particularly distinctive on the
wheel arches, the arches of the roofline, the front end and the rear end.Audi has taken this genetic code and
developed it in authentic style.
In the new TT, the geometric shapes merge fluidly with one another.The concave and convex arches radiate
dynamism and movement while lending the TT Coupé the character of an athletic sculpture thrusting
forwards.

The front end of the new TT Coupé has gained in expressiveness and resoluteness, the most distinctive
element being the singelframe radiator grille.

Unlike the predecessor model, the rear end has a completely different outline to the front end. The rear lights
create a three-dimensional effect by virtue of their visual depth. The trapezoidal cut-out around the license
plate continues the flowing lines of the boot lid. The powerful exhaust tailpipes, wide diffusor and central rear
fog light are borrowed straight from motorsport.

The dynamic impression conveyed by the Audi TT Coupé also stems from its modified proportions.

On the exterior it is now:  - 137 mm longer

- 78 mm wider

Excellence in design & performance

Self-study programmes on the TT Coupé

SSP 381 Audi TT Coupé ‘07 -
Suspension System

–

Front  axle

–

Rear  axle

–

Shock absorber system

–

Brake system

Order number: A06.5S00.26.20

SSP 382 Audi TT Coupé ‘07 -
Electrical and Infotainment Systems

–

Networking

–

Bus  topology

–

Convenience electronics

–

Infotainment

Order number: A06.5S00.27.20

380_043

SSP 380 Audi TT Coupé ‘07

–

Body

–

Occupant protection

–

Engine

–

Suspension system

–

Electrical system

–

Air conditioning

–

Infotainment

Order number: A06.5S00.25.20

SSP 383 Audi TT Coupé ‘07 - Body

–

Audi Space Frame

–

Production processes and joining methods

–

Surface  finish

–

Electromechanical rear spoiler

–

Repair concept

–

Passive safety concept

Order number: A06.5S00.28.20

Note

Reference

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  4

The self-study programme teaches the design and function of new vehicle models,
new automotive components or new technologies.

The self-study programme is not a repair manual!
All values given are intended as a guideline only, and refer
to the software version valid at the time of publication of the SSP.

For maintenance and repair work, always refer to the current technical literature.

Contents

Occupant protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  8

Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  22

Running gear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28

Electrical system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38

Body  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  6

Air conditioning  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  42

Infotainment  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50

4

Overview

Dimensions of the Audi TT Coupé ‘07.

Introduction

Audi TT Coupé ‘07

 2.0l HS

2.0l s-tronic

3.2l HS qu

3.2l s-tronic qu

Permissible gross weight in kg

1660

1680

1810

1830

Kerb weight without driver in kg

1260

1280

1410

1430

Drag coefficient Cw

0.30

0.30

0.31

Fuel tank capacity in litres

55

60

Body type

Audi Space Frame (ASF)

Height of loading sill in mm

790

Luggage compartment volume in l

290 (700l with rear-seat back folded forward)

380_054
