DTC P0752:
2005-2006 Models
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
14-181
Shift Solenoid Valve A Stuck ON
NOTE: Record all freeze data and review General
Troubleshooting Information (see page 14-8) before
you troubleshoot.
1. Warm up the engine to normal operating
temperature (the radiator fan comes on).
2. Make sure that the transmission is filled to the
proper level, and check for fluid leaks.
3. Drain the ATF (see step 3 on page 14-272) through a
strainer. Inspect the strainer for metal debris or
excessive clutch material.
Replace the transmission.
Replace the ATF (see step 4 on page 14-272)
then go to step 4.
4. Clear the DTC with the HDS.
5. Test-drive the vehicle in the D position through all
five gears at speeds over 12 mph (20 km/h) for
more than 20 seconds, then slow down to a stop.
6. Retest-drive the vehicle in the D position through
all five gears at speeds over 12 mph (20 km/h) for
more than 20 seconds, then slow down to a stop.
7. Monitor the OBD status for P0752 in the DTCs/
Freeze Data in A/T Mode Menu for a pass/fail.
Go to step 8.
Intermittent failure, the system is OK at this
time. If the tester indicates NOT COMPLETED,
return to step 5 and recheck.
8. Clear the DTC with the HDS.
9. Choose Shift Solenoid A in Miscellaneous Test
Menu, and check that the shift solenoid valve A
operates with the HDS.
Go to step 10.
Replace shift solenoid valve A (see page
14-260), then go to step 13.
10. Test-drive the vehicle in the D position through all
five gears at speeds over 12 mph (20 km/h) for
more than 20 seconds, then slow down to a stop.
11. Retest-drive the vehicle in the D position through
all five gears at speeds over 12 mph (20 km/h) for
more than 20 seconds, then slow down to a stop.
12. Monitor the OBD status for P0752 in the DTCs/
Freeze Data in A/T Mode Menu for a pass/fail.
Repair shift valve A, or replace the
transmission, then go to step 13.
Intermittent failure, the system is OK at this
time. If the tester indicates NOT COMPLETED,
return to step 10 and recheck.
13. Clear the DTC with the HDS.
14. Test-drive the vehicle in the D position through all
five gears at speeds over 12 mph (20 km/h) for
more than 20 seconds, then slow down to a stop.
15. Retest-drive the vehicle in the D position through
all five gears at speeds over 12 mph (20 km/h) for
more than 20 seconds, then slow down to a stop.
16. Monitor the OBD status for P0752 in the DTCs/
Freeze Data in A/T Mode Menu for a pass/fail.
Troubleshooting is completed.
Return to step 8 and recheck.
Does the str ainer contain metal debr is or
excessive clutch mater ial?
Does the r esult indicate a f ailed?
Is a clicking sound hear d?
Does the r esult indicate a f ailed?
Does the r esult indicate a passed?
