Acura RL (1996-2004 year). Manual - part 710
Short to power in the driver's side airbag inflator;
replace the driver's side airbag (see page
).
Faulty SRS unit; replace the SRS unit (see page
).
Check for a short to power in the driver's side airbag inflator:
1. Disconnect the negative battery cable, and wait for 3
minutes.
2. Disconnect the SRS floor harness 2P connector from the
driver's side airbag 2P connector (see page
).
3. Connect the special tool to the SRS floor harness 2P
).
4. Reconnect the negative battery cable.
5. Erase the DTC memory (see page
).
).
Check for a short to power in the SRS floor harness:
1. Disconnect the negative battery cable, and wait for 3
minutes.
2. Disconnect between the front passenger's side airbag 2P
and the SRS floor harness 2P connectors, between the
driver's seat belt tensioner 2P and the left side wire har-
ness 2P connectors, and between the front passenger's
seat belt tensioner 2P and the right side wire harness 2P
connectors (see page
).
3. Disconnect the SRS floor harness 18P connector from
).
4. Check resistance between the No. 2 and No. 7 terminals
of the SRS floor harness 18P connector, and between the
No. 2 and No. 8 terminals of the SRS floor harness 18P
connector. There should be 1 or more.
DTC11-4
CAUTION: Whenever the ignition switch is ON (II), or
has been turned OFF for less than 3 minutes, be careful
not to bump the SRS unit or the side impact sensor; the
airbags could accidentally deploy and cause damage or
injuries.
Try to reproduce the SRS indicator light:
1. Erase the DTC memory (see page
).
2. Turn the ignition switch ON (II), and check that the SRS
indicator light comes on for about 6 seconds, and then
goes off.
Intermittent failure, system is OK at this time. See
Troubleshooting Intermittent Failures on page
