Fig. 55: Identifying Blower Motor Connector, Blower Motor, Duct And Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Install the blower motor in the reverse order of removal.

SEAT CUSHION FRONT DUCT

1. Remove the front seat (see FRONT SEAT REMOVAL/INSTALLATION ).

2. Remove the seat-back (see SEAT-BACK/SEAT CUSHION ).

3. Remove the front seat cushion cover/pad (see FRONT SEAT CUSHION COVER

REPLACEMENT ).

4. Remove the screws, then remove the duct (A).

NOTE:



Take care not to tear the seams or damage the seat covers.



Put on gloves to protect your hands.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 34

© 2005 Mitchell Repair Information Company, LLC.

Fig. 56: Identifying Seat Cushion Front Duct
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Install the duct in the reverse order of removal.

REAR SEAT REMOVAL/INSTALLATION

1. Pull the seat hook knobs (A) while pushing down on the seat cushion (B), to release the hooks (C).

Fig. 57: Identifying Seat Hook Knobs, Seat Cushion And Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the seat cushion (A), and release the center seat belt buckles (B) from their slits (C).

NOTE:

Take care not to scratch the body or tear the seat covers.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 35

© 2005 Mitchell Repair Information Company, LLC.

Fig. 58: Identifying Seat Cushion, Center Seat Belt Buckles And Slits
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Release the seat belt (A) from their guides (B).

Fig. 59: Identifying Seat Belt And Guides
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove the rear center seat belt and rear seat belt buckles (see step 2 under CENTER SEAT BELT

AND SEAT BELT BUCKLES ).

5. Remove the bolts from the base of the seat-back (A).



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 36

© 2005 Mitchell Repair Information Company, LLC.

Fig. 60: Identifying Rear Seat-Back And Fasteners With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Disconnect the power head restraint connector (B).

7. Lift the seat-back (A) up to release the wire loops (B) from the hooks (C) on the body, then remove

the seat-back.

Fig. 61: Identifying Seat-Back, Wire Loops, Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Install the seat in the reverse order of removal, and note these items:



Guide the belts over the front of the seat-back as you install it.



Before attaching the rear seat-back and cushion, make sure there are no twists or kinks in the
seat belts.



When installing the seat cushion, slip the seat belt buckles through the slits in the seat cushion.

REAR SEAT ARMREST BEVERAGE HOLDER REPLACEMENT
