Page 18
Lotus Service Notes
Section MP Positive post on bulkhead Chassis Chassis front earth To ECU earth point stud plate To transmission Positive binding housing post on scuttle
m191b
Positive binding post on scuttle Chassis front earthing point Starter solenoid Battery negative Battery positive
m191b Chassis rear earth point Battery cables; positive & negative posts sn_mp_ cyclone.indd 18 02/01/2008 04:42:10 |
