Lotus Service Notes Section PL Page 7 Interior Climate Controls The interior climate controls consist of two push switches (if fitted) for air condition- Air Conditioning (if fitted) The left hand push button switch requests air conditioning, but the engine must be run- With a fully cold temperature setting, refrigerated air will be supplied. For dehu- The tell tale in the switch button lights up green when the circuit is active. Air Re-circulation (with a.c.) Air supply for the interior climate system is normally drawn from both the intake duct ahead of the engine cooling radiator, and the vehicle interior. When the re-circulation button is pressed, a stepper motor is acti- Heater Temperature With the left hand rotary electrical control turned fully counterclockwise, the air blender flaps are posi- tioned to direct all the airflow to by-pass the heater chamber so that no air heating is provided. If air cooling is Fan Speed The centre rotary switch provides three fan speeds to boost air circulation. Turned fully counterclockwise, the fan is off; Turning the switch progressively clockwise operates the blower fan at increasing speed in three Air Distribution The right hand electrical rotary control operates a stepper motor on the air distribution unit to direct airflow to the windscreen, face level and footwell vents. The following diagrams indicate airflow for the different
p99 Temperature Fan Speed Distribution Air conditioning Re-circulation (if fitted) (if fitted)
INTERIOR CLIMATE CONTROLS
