4. Release plug connection -3- -arrow a- and disconnect -arrows B- . 5. Pull off the white hose -4- from the air cushion control valve -arrow C- and remove the air cushion motor Installing air cushion motor Installing air cushion motor Installing air cushion motor 1. Position air cushion motor -2- and push on the white hose -4- onto the air cushion control valve -arrow A- . 2. Push the plug connection -3- together -arrows B- until it is felt to engage. Note Observe hose routing! 3. Secure air cushion motor -2- onto support using two new tie-wraps -1- . Diagnostic system: reading out fault memory and activating systems Installing air cushion motor 3273 |
