Pushing hose onto the control valve for lumbar support 4. Push the white hose -1- onto the control valve for lumbar support -2- . Checking seat following removal 1. Connect the removed seat to the vehicle's wiring harness via test cable 9745 and test cable . 2. Connect electric plug to control module trim panel. → 721619 Removing and installing control module trim panel - section on "Installing" 3. Connect the battery. → 2706IN IN -Work instructions after disconnecting the battery 4. Switch on ignition. 5. Carry out a function check on the seat components. 6. Switch off ignition after function test and disconnect battery. 7. Disconnect test cable 9745 and test cable . Fitting foam part Fitting foam part Note Observe the installation position of the hoses! Diagnostic system: reading out fault memory and activating systems Installing motor for lumbar support 3261 |
