Gap dimensions of sill cover Sill cover to door sill Location Explanation Type Basic value Tolerance 1 Tolerance 2 Sill cover to door sill Gap dimension A 1.3 mm +0.5 mm Sill cover to door sill Door sill only lowered Gap dimension B 2 mm -1 mm Sill cover to door sill at rear in wheel housing Location Explanation Type Basic Tolerance 1 Tolerance 2 Sill cover to door sill rear in wheel Gap dimension 1.3 mm +0.5 mm Diagnostic system: reading out fault memory and activating systems Gap dimensions of sill cover 2621 |
