Inserting door trim panel

Installation Location:

Installation position of front door window

Lock plug connection to control module.

1. Connect electrical plug connection -1- to control module -2- by operating locking lever -3- and lock.

Locking electrical plug connection

2. Lock electrical plug connection -arrow- until it engages audibly.

Diagnostic system: reading out fault memory and activating systems

Inserting door trim panel

2497

Hooking in door trim panel

3. Hook front door trim panel into sealing channel at the

top.

Standardising the power windows

The system must be re-standardised after an interruption in the power supply to the power window electronics
in the door. The position values for the short-stroke lowering function, position-controlled lowering function
in the case of convertible top actuation and enabling for "automatic start-up of window closing" (one-touch
function) are redefined. The standardisation process is initiated by continuous actuation of the operating
button Raise window .

–  Hold down the Raise window button until the window is closed and is switched off by the blockage

detection function of the power windows.

Blockage detection function

Note

If the window drive encounters resistance during the door window movement, the motor is switched
off after a delay of 500 ms.

•

Precondition for operation of the power windows

Ignition switched on.
Ignition key should not be removed from the steering lock with the ignition switched off.
The door is opened for the first time after switching off the ignition.
Door opened.

Adjusting the door window angle in the vehicle's longitudinal direction

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Standardising the power windows

2498

Installation position of front door window

1. Raise door window. Fastening screws are accessible.

2. Release electrical plug connections for door trim panel and remove door trim

panel.

Adjusting the door window angle in the vehicle's longitudinal direction

3. Adjust to equalise the angle of the door window on the clamping jaws of the driver (upwards or

downwards) -A- . Adjustment range: 10 mm

4. Tighten the fastening screw -1- on the clamping jaw -2- after completing the adjustment. Tightening

torque → Final tightening: 8.5 (6.25) Nm (ftlb.) +/-1.5 (1) Nm (ftlb.)

Adjusting the door window height

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Adjusting the door window angle in the vehicle's longitudinal direction

2499

Installation position of front door window

Note

The wax marking along the door window should be uniformly approx. 4 mm.

•

Adjusting the door window height

Note

The adjusting screws of the drivers for the upper limit stops for the door window height are accessible
through 2 holes at the bottom of the door.

•

1. Adjust the upper limit stops of the drivers by screwing the fastening screw in or out using socket E6 in or

against the direction of travel. Adjustment range: approx. 15 mm

Note

The adjusting screws of the drivers for the upper limit stops for the door window height are accessible
through 2 holes at the bottom of the door.

•

2. Adjust the drivers so that they meet the upper limit stops at the same time.

Diagnostic system: reading out fault memory and activating systems

Adjusting the door window height
