Removing connectors at sliding roof switch and interior light

5. Release connecters at sliding roof switch and at the interior light -arrows a- and remove them. Remove

cover for motor for sliding roof.

Removing switch for sliding roof

Removing switch for sliding roof

1. Release the four locking tabs on the cover of the motor for sliding roof -arrows a- and remove the switch

for sliding roof.

Installing switch for sliding roof

Installing switch for sliding roof

Diagnostic system: reading out fault memory and activating systems

Removing cover for motor for sliding roof

2069

Installing switch for sliding roof

1. Press switch for sliding roof into the cover of the motor for sliding roof until the four locking tabs

-arrows-

 are felt to engage.

Installing cover for sunroof motor

Plugging in connectors on interior light and sunroof switch

1. Position cover for sunroof motor. Plug in the connectors on the interior light and the sunroof switch until

they are felt to engage.

Clipping in cover of sunroof motor

2. Using the clips, engage cover for sunroof motor on roof frame -arrow A- , push back towards sunroof

-arrow B-

 and clip in at the rear to the left and right -arrows C- .

Diagnostic system: reading out fault memory and activating systems

Installing switch for sliding roof

2070

Clipping in cover for fastening screws

3. Insert cover of fastening screws into the mounts on the sunroof motor cover -arrows- and clip it in.

4. Switch on ignition and check that sunroof switch and interior light are

working.
