Installation position of rear centre panel Installing rear centre panel Note Observe installation position of seal for rear centre panel to rear window. 1. Position rear centre panel -2- . 2. By shifting the contours in relation to the side panel and rear lid, adjust the gap dimensions as required and tighten with the fastening screws -1- . Tightening torque → Tightening torque: 7.5 3. Retract rear spoiler. Fastening inner rear centre panel Installation Location: Diagnostic system: reading out fault memory and activating systems Installing rear centre panel 1601 |
