3 - Screw (6x80) 4 - Screw (6x55) 5 - Leaf springs 6 - Solenoid valve, 2-3 gearshift 7 - Control solenoid valve, converter jumper 8 - Solenoid valve, 1-2 and 4-5 gearshift 9 - Solenoid valve, 3-4 gearshift 10 - Control solenoid valve, shifting pressure 11 - Control solenoid valve, modulating pressure 12 - Electrical control unit 13 - Hydraulic control unit Disconnecting hydraulic and electrical control unit Disconnecting control units 1. Remove electrical control unit. To do so, bend back the retaining lug -arrow- at the strengthening rib on the oil temperature sensor and remove electrical control unit from hydraulic control unit by pulling it Removing solenoid and control valve 1. Pull off plastic cover. 2. Remove screw. 3. Remove leaf spring. 4. Pull solenoid and control valve out using pullers, if necessary. Diagnostic system: reading out fault memory and activating systems Overview 1049 |
