To make it easier to remove the bearing cover, spray the sealing surface with anti-rust agent. • 7. Unscrew M8 hexagon collar nut on the bearing cover of the intermediate shaft with special tool socket , while at the same time countering the slotted threaded pin on the intermediate shaft with a screwdriver. 8. Unscrew the three M6 x 20 fastening screws (coated) on the intermediate-shaft flange. Replace screws during installation and clean thread in crankcase. Puller on bearing cover: view when removed Note Remove bearing cover using special tool puller 9673. If this is not available, lever the bearing cover • After removing the bearing cover, do not press the threaded bolts of the intermediate shaft. • Note Remove bearing cover using special tool puller 9673. If this is not available, lever the bearing cover • After removing the bearing cover, do not press the threaded bolts of the intermediate shaft. • 9. Position special tool puller 9673 at the bearing cover grooves and secure by turning the locking lever anti-clockwise. Diagnostic system: reading out fault memory and activating systems Removing bearing cover for intermediate shaft - up to engine number 685 09790 425 |
