Scania 3250 Instrumentation en-GB 2 490 157



Operator's manual
3250
Instrumentation
en-GB 2 490 157
Issue 3.0
Introduction
3
Functions
3
Alarms and stopping the engine
3
Instrument panel
4
Display pages and structure
6
Values which are read from the engine control
unit
7
Alarms from the engine control unit
8
Changing settings
9
Entering the password
10
Selecting language and user
11
Adjusting the display contrast
11
List of alarms from the coordinator
12
Components in the central electric unit
13
2
Introduction
• Measuring generator data: power, measuring
Introduction
effective voltage and current (RMS).
This Operator’s manual describes the operation
• Graphics of engine temperature, oil pressure
of instrument panel 3250 for Scania generator
and fuel level.
sets.
• CAN communication with the engine control
The information in this Operator's manual was
unit for diagnostics.
correct at the time of going to press. Scania re-
• History log with the last 119 alarms.
serves the right to make alterations without prior
notice.
Note:
Alarms and stopping the en-
Always use Scania spare parts for repair work.
gine
Instrument panel 3250 has alarm functions for:
• Undervoltage and overvoltage.
Functions
• Underfrequency and overfrequency.
• Excess current.
Instrument panel 3250 is a microcontroller-
based instrument panel used to start and switch
• Failed engine start or engine shutdown.
off the generator set manually or automatically
• Undervoltage and overvoltage for battery.
via an external signal.
• Imbalanced load between phases or phase
The instrument panel runs and monitors parame-
fault.
ters to ensure trouble-free operation of the gener-
• High engine temperature.
ator set. The instrument panel display displays
• Emergency stop.
the operational status and display messages.
• Low oil pressure.
Instrument panel 3250 has the following func-
• Maintenance reminder.
tions:
• Configurable binary input for alarm and en-
• Manual and automatic startup and shutdown
gine shutdown.
of the generator set.
• Oil pressure sensor error.
• Engine shutdown and alarms.
• Coolant temperature sensor error.
• Measuring engine data: engine temperature,
• Alarms and diagnostic messages from the en-
oil pressure, fuel level, operating time and
gine control unit.
maintenance reminder.
3
Instrument panel
Instrument panel
The illustration displays the instrument panel switches, indicator lamps and display.
InSight3250
5
6
1
Mode
Mode
Star t
13
2
Horn
Fault
Stop
reset
reset
o
4
3
8
7
Page
12
9
G
Enter
11
10
Switches for generator set
Position
Switch
Function
Start the engine. The switch is only activated in manual operating mode (MAN).
Start
1
Stop the engine. The switch is only activated in manual operating mode (MAN).
Stop
When you press the switch, the generator set stop sequence is initiated. If you
2
press the switch several times or press it in for over two seconds, the current phase
o
of the stop sequence is cancelled (e.g. cooling), and the next phase is started.
Acknowledge alarm and switch off the alarm signal. Acknowledged alarms disap-
Fault
pear immediately and active alarms are changed to acknowledged. An alarm mes-
3
reset
sage disappears when the cause has been resolved.
4
Deactivate alarm signal without acknowledging the alarm.
Horn
reset
Change operating mode between OFF, MAN, AUT, TEST. The switch is activated
Mode
when the main view with the selected operating mode is displayed. The switch is
5
deactivated when the operating mode has been selected externally.
4
Instrument panel
Switches for generator set
Change operating mode between OFF, MAN, AUT, TEST. The switch is activated
Mode
when the main view with the selected operating mode is displayed. The switch is
6
deactivated when the operating mode has been selected externally.
Indicator lamps
Position
Function
Red indicator lamp, flashes when an alarm is triggered. When you press switch 3 (Fault reset), the
7
indicator lamp is constantly on when alarm is still active, or it turns off when no alarm is active.
Green indicator lamp, on when there is generator voltage and it is within the limits. The generator
8
voltage and frequency limits depend on the parameters set in the Gener Protect group on the Set-
points page.
Switches for display and control
Position
Switch
Function
Go to next page.
Page
9
Finish editing a setting or go to the right in the history log.
Enter
10
Page down or decrease a setting value in edit mode.
11
Page up or increase a setting value in edit mode.
12
13
Graphic black/white display.
5
Display pages and structure
Display pages and structure
The information displayed is structured in three pages with subordinate views. You can change pages with
the Page switch.
1. The Measurement page consists of views that display measurement values such as voltages, current, oil
pressure and calculated values such as generator power and statistical data. The alarm list from the pre-
vious view is also shown there.
2. The Setpoints page consists of views with settings divided into groups, and a separate group for entering
the password.
3. The History log page shows the history log, where the last event is displayed first.
Note:
The Setpoints and History log pages are only accessible when Engineer is selected as the user (not User).
See the section Selecting language and user.
Measurement
Setpoints
History log
OFF MAN AUT TEST !
Password
No. Reason
>Basic Settings
>
0 Switched On
Not ready
Engine Params
-1 Fault reset
MainsFlt
Engine Protect
-2 Emergency Stop
Page
Page
Page
PF
0.00
Gener Protect
-3 Wrn RA15 Fail
R
0
AutoMains Fail
-4 Sprinkler Set
No Timer
Extension I/O
-5 Config Loaded
0 kW
0
Date/Time
13:02:17 07/08/2008
Enter
Page
Enter
Generator
Gen-set Name
Time
Date
L1N
0 L1L2
0V
>13:02:17 07/08/2008
L1N
0 L1L
V
>Nominal Power
13:00:46 07/08/2008
L1N
0 L1L2
0V
200 kW
13:00:46 07/08/2008
Page
Page
Gen freq
0.0Hz
Nomin Current
13:00:45 07/08/2008
350
A
13:00:45 07/08/2008
0
0
0 A
CT Ratio
13:00:43 07/08/2008
2000 /5A
0 Switched On
Enter
Page
Enter
Enter
ECU AlarmList
Gen-set Name
Mode
RPM
Pwr
>EngOil Press
> OFF
0
0
000225 (000E1h)
>Nominal Power
0
0
250
200 kW
OFF
0
0
Page
Page
Nomin Current
OFF
0
0
350
A
OFF
0
0
CT Ratio
OFF
0
0
FC
100 OC 4 FMI
1
2000 /5A
0 Switched On
Enter
AlarmList
1
Emergency Stop
Page
6
Display pages and structure
Values which are read from
the engine control unit
The instrument panel can read and generate
alarms for the following values from the engine
control unit:
• Engine speed.
• Oil pressure.
• Engine coolant temperature.
• Total operating time until next maintenance.
• Fuel level (only if the generator set has the
fuel level monitor option).
• Boost pressure.
• Intake temperature.
• Engine oil temperature.
Note:
Only alarms are written in the history log. Other
values that have been read from the engine con-
trol unit are not registered.
7
Display pages and structure
Alarms from the engine control unit
AlarmList
1
*MCB Fail
2
*Emergency Stop
3
SD Override
1. Inactive non-acknowledged alarm
2. Active non-acknowledged alarm
3. Active acknowledged alarm
How to scroll through the alarms from the engine control unit:
ECU AlarmList
ECU AlarmList
ECU AlarmList
>*EngOil Press
*EngOil Press
*EngOil Press
*EngCool Temp
>*EngCool Temp
*EngCool Temp
Coolant Level
Coolant Level
>Coolant Level
Enter
Enter
Enter
FC
100 OC 4 FMI
1
FC
110 OC 1 FMI
0
FC
111 OC 2 FMI
2
alarm
Enter +Fault
reset
deactivation
ECU AlarmList
ECU AlarmList
>EngOil Press
>*EngOil Press
Coolant Level
*EngCool Temp
FC
100 OC 4 FMI
1
FC
100 OC 4 FMI
1
alarm
Enter +Fault
deactivation
reset
ECU AlarmList
>
FC
0 OC 0 FMI
0
8
Display pages and structure
Changing settings
OFF MAN AUT TEST !
Password
>Basic Settings
Not ready
Engine Params
MainsFlt
Engine Protect
Page
PF
0.00
Gener Protect
RPM
0
AutoMains Fail
No Timer
Extension I/O
0
0
Date/Time
Enter
Page
Gen-set Name
>Nominal Power
200 kW
*Nomin Current
350
A
CT Ratio
2000 /5A
Enter
Page
Enter
Gen-set Name
>Nominal Power
250
200 kW
*Nomin Current
350
A
CT Ratio
2000 /5A
Note:
Settings with an asterisk are password-protected. If you want to change them, you must first enter the pass-
word according to the instructions in the next section.
9
Display pages and structure
Entering the password
OFF MAN AUT TEST !
>Password
Basic Settings
Not ready
Engine Params
MainsFlt
Engine Protect
Page
PF
0.00
Gener Protect
RPM
0
AutoMains Fail
No Timer
Extension I/O
0 kW
0
Date/Time
Enter
Page
>EnterPassword
Changepassword
Enter
Enter
Page
>EnterPassword
0
Changepassword
Note:
If you do not have the password: Access the information view with the serial number (Serial) and the pass-
word decode number (Pwd. dec.) according to the instructions in the next section. Then send the numbers
to your Scania distributor.
10
Display pages and structure
Selecting language and user
OFF MAN AUT TEST !
InteliLite NT
ComAp 2007-2008
Not ready
Enter + Page
MainsFlt
IL-NT-x.y
PF
0.00
Serial:12345678
RPM
0
SW ver: x.y, x.y
No Timer
Appl
: AMF25
0 kW
0
Branch: Standard
Page
Languages
>English
Chinese
Enter
Page
User interface:
User
>Engineer
Enter
Serial:
12345678
Pwd. dec.: 1234567890
Page
Adjusting the display contrast
OFF MAN AUT TEST !
Not ready
MainsFlt
PF
0.00
OFF MAN AUT TEST !
RPM
0
No Timer
Not ready
Enter +
0 kW
0
MainsFlt
PF
0.00
OFF MAN AUT TEST !
Enter +
RPM
0
No Timer
Not ready
0 kW
0
MainsFlt
PF
0.00
RPM
0
No Timer
0 kW
0
11
List of alarms from the coordinator
List of alarms from the coordinator
If the external expansion card has been installed (see position 10 in Components in the central electric unit),
the alarm can be used to control an external output, e.g. switching on a light or emitting an acoustic signal.
Alarm
Safety precaution
Description
AI1 Wrn
Alarm
Extra protection against low oil pressure. Activated at
2.4 bar.
AI1 Sd
Engine shutdown
Extra protection against low oil pressure. Activated at
2.0 bar.
AI2 Wrn
Alarm
Extra protection against high coolant temperature.
AI2 Sd
Engine shutdown
Extra protection against high coolant temperature.
AI3 Wrn
Alarm
Low fuel level warning, if the fuel level monitor op-
tion has been selected.
AI3 Sd
Engine shutdown
Low fuel level warning, if the fuel level monitor op-
tion has been selected.
Binary input
Configurable
Configurable alarm or engine shutdown for the inputs
for IL-NT, which are built-in in the instrument panel.
Binary input 1 is used for emergency stop and binary
input 2 for remote start.
IL-NT-BIO8
Configurable
Configurable alarm or engine shutdown for the inputs
for IL-NT-BIO8, if the expansion card has been se-
lected as an option.
Wrn Batt Volt
Alarm
The battery voltage is beneath the set limit values for
Batt Undervolt/Batt OverVolt.
ChargeAlt Fail
Alarm
Fault when the alternator tried to charge the battery.
Sd BatteryFlat
Engine shutdown
If the instrument panel is switched off during the start-
ing sequence of the engine due to a voltage drop, the
instrument panel will not try to start the engine again.
Instead, engine shutdown is activated.
Sd Start Fail
Engine shutdown
Starting fault. All start attempts have been carried out
but failed.
Wrn Stop Fail
Alarm
Shutdown fault. A shutdown fault occurs if the stop
button is pressed and the instrument panel is still read-
ing the values for voltage, rpm or oil pressure.
Sd Gen Lx >V (where x =
Engine shutdown
The alternator voltage is outside the Gen >V Sd limit
1, 2, 3)
values.
12
Components in the central electric unit
Components in the central electric unit
The illustration below shows the location of the components inside the central electric unit. The illustration
shows all options. The central electric unit ordered can therefore have other equipment.
1
8
9
2
10
11
3
4
12
13
5
6
7
14
Pos.
Designation
Description
1
MCB1
Miniature circuit breaker for engine control unit, 20 A
2
MCB2
Miniature circuit breaker for instrument panel, 10 A
3
MCB5
Miniature circuit breaker for engine heater, 6 A
4
MCB6
Miniature circuit breaker for battery charger, 6 A
5
FCR
Relay for fuel valve
6
ECR
Not used
7
HCR
Relay for engine heater, instrument panel heater element and generator
heater
8
Expansion card
For remote connection via GSM/GPRS
9
Expansion card
For remote connection via network
10
Expansion card
8 additional inputs and outputs
11
Switch
For changing between 50/60 Hz
12
OH2/FLZ510
Heater element for instrument panel/thermostat
13
Battery charger
For 220/240 V electrical power network
14
Hobut
Residual current device
13















//////////////
