Nissan GT-R (2007-2014 year). PARKING BRAKE SYSTEM / REAR AXLE. Service Manual





PB-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Working Range at a Regular Dealership

INFOID:0000000009167682

CAUTION:

The service items unmentioned on this manual are recommended to be performed by a GT-R certified
NISSAN dealer. Because those service items require special equipment and a GT-R certified technical
staff who completed special training.

General Precautions

INFOID:0000000009159888

CAUTION:

After finishing servicing, check that all the tools and waste are stored in a customary place.

Revision: 2012 November

2014 GT-R

PREPARATION

PB-3

< PREPARATION >

C

D

E

G

H

I

J

K

L

M

A

B

PB

N

O

P

PREPARATION

PREPARATION

Commercial Service Tool

INFOID:0000000009159889

Tool name

Description

Power tool

Loosening bolts and nuts

PBIC0190E

Revision: 2012 November

2014 GT-R

PB-4

< PERIODIC MAINTENANCE >

PARKING BRAKE SYSTEM

PERIODIC MAINTENANCE

PARKING BRAKE SYSTEM

Inspection and Adjustment

INFOID:0000000009159890

INSPECTION

Parking Brake Lever Stroke

1.

Operate the parking brake lever with a force of 196 N (20 kg, 44 lb). Check that the lever stroke is within
the specified number of notches. (Check it by listening to the clicks of the ratchet.)

2.

When brake warning lamp turns ON, check that the lever stroke is within the specified number of notches.
(Check it by listening to the clicks of the ratchet.)

Inspect Components

• Check each component for installation condition such as looseness.
• Check the parking brake lever assembly for bend, damage and cracks. Replace if necessary.
• Check the cables and equalizer for wear, damage and cracks. Replace if necessary.
• Check the parking brake switch, and replace it if necessary. (This work is recommended to be performed by

GT-R certified NISSAN dealer.)

ADJUSTMENT

1.

Remove tires with power tool. Refer to

WT-11, "Exploded View"

.

2.

Fix the disc rotor using wheel nuts.

3.

Remove the instrument garnish. Refer to

IP-12, "Exploded View"

.

4.

Remove the console finisher assembly. Refer to

IP-23, "Exploded View"

.

5.

Remove the cup holder finisher. Refer to

IP-23, "Exploded View"

.

6.

Rotate the adjusting nut (1) and loosen the cable, and then
return the parking brake lever.

7.

Remove the adjusting hole plug from the disc rotor. Turn the
adjuster (1) in the direction (A) as shown in the figure using a
suitable tool until the disc rotor is locked.

8.

Turn back the adjuster 5 or 6 notches from the locked position.

9.

Rotate the disc rotor to check that there is no drag. Install the
adjusting hole plug. If there is any drag, refer to

PB-6, "Inspec-

tion and Adjustment"

.

10. Adjust the cable with the following procedure.

a.

Operate the parking brake lever with a force of 294 N (30 kg, 66
lb) for 10 strokes or more.

b.

Adjust the parking brake lever stroke by turning the adjusting
nut.

CAUTION:

Never reuse the adjusting nut if the adjusting nut removed.

Number of notches

: Refer to

PB-8, "Parking Brake Control"

.

Number of notches

: Refer to

PB-8, "Parking Brake Control"

.

NNFIB0001ZZ

JPFIB0002ZZ

Revision: 2012 November

2014 GT-R

PARKING BRAKE SYSTEM

PB-5

< PERIODIC MAINTENANCE >

C

D

E

G

H

I

J

K

L

M

A

B

PB

N

O

P

c.

Operate the parking brake lever with a force of 196 N (20 kg, 44 lb). Check that the lever stroke is within
the specified number of notches. (Check it by listening to the clicks of the ratchet.)

d.

Rotate the disc rotor with the parking brake lever released and check that there is no drag. Refer to

PB-6,

"Inspection and Adjustment"

.

Number of notches

: Refer to

PB-8, "Parking Brake Control"

.

Revision: 2012 November

2014 GT-R

PB-6

< REMOVAL AND INSTALLATION >

PARKING BRAKE SHOE

REMOVAL AND INSTALLATION

PARKING BRAKE SHOE

Exploded View

INFOID:0000000009159895

Inspection and Adjustment

INFOID:0000000009159897

INSPECTION AFTER REMOVAL

Lining Thickness Inspection

Check thickness (A) of lining.

Drum Inner Diameter Inspection

Check inner diameter (B) of drum.

1.

Back plate

2.

Parking brake shoe

3.

Adjuster

4.

Adjuster spring

5.

Return spring

6.

Anti-rattle spring

7.

Retainer

8.

Anti-rattle pin

9.

Toggle lever

: Apply PBC (Poly Butyl Cuprysil) grease or silicone-based grease.

NNFIB0005ZZ

A

: Refer to

PB-8, "Parking Drum Brake"

.

SBR021A

B

: Refer to

PB-8, "Parking Drum Brake"

.

JPFIB0008ZZ

Revision: 2012 November

2014 GT-R

PARKING BRAKE SHOE

PB-7

< REMOVAL AND INSTALLATION >

C

D

E

G

H

I

J

K

L

M

A

B

PB

N

O

P

Other Inspections

Check the following items, and replace the parts if necessary.
• Lining for excessive wear, damage or peeling.
• Brake shoe sliding surface for excessive wear or damage.
• Anti-rattle pin and retainer for excessive wear, damage or rust.
• Adjuster spring, return spring and anti-rattle spring for settling, excessive wear, damage or rust.
• Adjuster for smoothness.
• Toggle lever for excessive wear, damage or rust.
• Visually check inside of the drum for excessive wear, cracks or damage with a pair of vernier calipers.

ADJUSTMENT AFTER INSTALLATION

Check the parking brake for drag. Perform the following procedure if necessary.

1.

Adjust the parking brake lever stroke. Refer to

PB-4, "Inspection and Adjustment"

.

2.

Check the parking brake for drag again. Check the rear disc brake for drag if necessary. (This work is rec-
ommended to be performed by GT-R certified NISSAN dealer.)

Revision: 2012 November

2014 GT-R

PB-8

< SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

Parking Drum Brake

INFOID:0000000009159898

Unit: mm (in.)

Parking Brake Control

INFOID:0000000009159899

Item

Limit

Brake lining

1.5 (0.059)

Drum (disc of inner diameter)

191 (7.52)

Item

Standard

Number of notches [under force of 196 N (20 kg, 44 lb)]

5 – 6 notches

Number of notches when brake warning lamp turns ON

1 notch

Revision: 2012 November

2014 GT-R

RAX-2

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000009163173

Use chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference

—

T

h

is

 wo

rk i

s

 rec

o

m

m

e

n

d

e

d

 to

 be

 p

e

rfo

rme

d

by

 G

T

-R ce

rti

fie

d NIS

SAN d

eal

er

.

—

T

h

is

 wo

rk i

s

 rec

o

m

m

e

n

d

e

d

 to

 be

 p

e

rfo

rme

d

by

 G

T

-R ce

rti

fie

d NIS

SAN d

eal

er

.

—

NVH in DLN

section.

NVH in DLN

section.

NVH

in

RAX and RSU sections.

Re

fe

r to

REAR AXL

E i

n

 t

h

is cha

rt.

NVH in WT

section.

NVH in WT

section.

Re

fe

r to

DRIVE SHA

FT i

n

 t

h

is cha

rt.

NVH in BR

section.

NVH in ST

section.

Possible cause and SUSPECTED PARTS

Ex

ce

ss

iv

e joi

nt an

gle

Jo

in

t sl

id

in

g

 re

si

st

a

n

c

e

Im

ba

la

nc

e

Imp

rop

er i

ns

ta

lla

ti

o

n,

 lo

os

en

es

s

Part

s int

e

rference

PROPELLER S

H

A

F

T

DIFF

ERENTIAL

REAR AX

LE A

N

D

 REAR SUSPE

N

S

ION

REAR AX

LE

TIRE

ROAD WHEEL

DRIVE SHAFT

BRAKE

STE

E

RING

Symptom

DRIVE
SHAFT

Noise

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

REAR AXLE

Noise

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

Vibration

×

×

×

×

×

×

×

Shimmy

×

×

×

×

×

×

×

Judder

×

×

×

×

×

×

Poor quality ride or handling

×

×

×

×

×

Revision: 2012 November

2014 GT-R

PRECAUTIONS

RAX-3

< PRECAUTION >

C

E

F

G

H

I

J

K

L

M

A

B

RAX

N

O

P

PRECAUTION

PRECAUTIONS

Precaution for Working Range at a Regular Dealership

INFOID:0000000009188290

CAUTION:

The service items unmentioned on this manual are recommended to be performed by a GT-R certified
NISSAN dealer. Because those service items require special equipment and a GT-R certified technical
staff who completed special training.

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000009163174

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.

WARNING:

Always observe the following items for preventing accidental activation.
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see “SRS AIR BAG”.

• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-

vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

Always observe the following items for preventing accidental activation.
• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the

ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with
a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing
serious injury.

• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the

battery, and wait at least 3 minutes before performing any service.

General Precautions

INFOID:0000000009163175

CAUTION:

After finishing servicing, check that all the tools and waste are stored in a customary place.

Revision: 2012 November

2014 GT-R

RAX-4

< PERIODIC MAINTENANCE >

REAR WHEEL HUB AND HOUSING

PERIODIC MAINTENANCE

REAR WHEEL HUB AND HOUSING

Inspection

INFOID:0000000009163180

MOUNTING INSPECTION

Check the mounting conditions (looseness, back lash) of each component and component conditions (wear,
damage) are normal.

WHEEL BEARING INSPECTION

• Move wheel hub and bearing assembly in the axial direction by hand. Check there is no looseness of wheel

bearing.

• Rotate wheel hub, and check that is no unusual noise or other irregular conditions. If there is any of abnor-

mal conditions, replace wheel hub and bearing assembly.

Axial end play

: 0.05 mm (0.002 in) or less

Revision: 2012 November

2014 GT-R

REAR DRIVE SHAFT

RAX-5

< PERIODIC MAINTENANCE >

C

E

F

G

H

I

J

K

L

M

A

B

RAX

N

O

P

REAR DRIVE SHAFT

Inspection

INFOID:0000000009163181

• Check drive shaft mounting point and joint for looseness and other damage.
• Check boot for cracks and other damage.

CAUTION:

Replace entire drive shaft assembly when noise or vibration occurs from drive shaft.

Revision: 2012 November

2014 GT-R

RAX-6

< REMOVAL AND INSTALLATION >

REAR WHEEL HUB AND HOUSING

REMOVAL AND INSTALLATION

REAR WHEEL HUB AND HOUSING

Exploded View

INFOID:0000000009163182

1.

Ball seat

2.

Axle housing

3.

Bushing

4.

Cotter pin

5.

Back plate

6.

Anchor block

7.

Wheel hub and bearing assembly

8.

Spring washer

9.

Wheel hub lock nut

A.

When tightening wheel hub lock nut, tighten the lock nut to 225 N·m (23 kg-m, 166 ft-lb), loosen it, and retighten it to 350 N·m
(36 kg-m, 258 ft-lb) to break in spring washer and the contact surface of wheel hub assembly.

: Apply anti-corrosion oil.

Refer to

GI-4, "Components"

 for the symbols in the figure.

JSDIA3974GB

Revision: 2012 November

2014 GT-R



















///////////////////////////////////////
