Pramac energy generation. Product catalogue

PORTABLE Range / Gensets

E series

ESSENTIAL ENERGY

Simple professional generators; maximum reliability and

performance, with a basic but efficient configuration.

GENERATING SET

E3200

E4000

E5000

E8000

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

5,0/6,3

6,6/8,3

(POWER COP) kW/kVA

4,3/5,4

5,6/7,0

SINGLE PHASE

(POWER LTP) kW/kVA

2,6/2,9

3,1/3,4

4,6/5,1

3,7/4,2

6,4/7,2

4,9/5,5

(POWER COP) kW/kVA

2,2/2,5

2,6/2,9

3,9/4,2

2,8/3,1

5,5/6,0

3,7/4,1

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

FREQUENCY Hz

POWER FACTOR cosФ

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

BRAND

Honda

MODEL

GX160

GX200

GX270

GX390

FUEL

Petrol

DISPLACEMENT cc

163

196

270

389

SPEED rpm

3000

CYLINDER

1 inclined

COOLING SYSTEM

Air

STARTING SYSTEM

Recoil

CONSUMPTION

CONSUMPTION at 75% of load L/h

0,9

1,1

1,6

2,2

TANK CAPACITY L

3,1

5,3

6,1

RUNNING TIME at 75% of load h

3,4

2,8

3,3

2,9

NOISE EMISSION

NOISE PRESSURE LEVEL at 7 m dB(A)

GUARANTEED SOUND POWER LEVEL LWA dB(A)

DIMENSIONS AND WEIGHT

LENGTH mm

640

715

750

WIDTH mm

458

540

578

HEIGHT mm

400

490

531

WEIGHT (dry) Kg

SOCKET TYPE

2 x SCHUKO

1 x 230V 16A

1 x SCHUKO

1 x 230V 16A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

ALTERNATOR AND SOCKET PROTECTION

ELECTRIC PROTECTION

IP 23

SOCKET PROTECTION

IP 54

IP 44

COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

E series

ESSENTIAL ENERGY

Simple professional generators; maximum reliability and

performance, with a basic but efficient configuration.

GENERATING SET

E4500*

E6500*

E6000*

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

3,7/4,7

5,5/6,9

(POWER COP) kW/kVA

3,2/4,0

4,5/5,7

SINGLE PHASE

(POWER LTP) kW/kVA

3,5/3,9

2,8/3,1

5,3/5,9

4,1/4,6

(POWER COP) kW/kVA

3,0/3,3

2,0/2,3

4,4/4,8

3,2/3,5

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

FREQUENCY Hz

POWER FACTOR cosФ

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

BRAND

Yanmar

MODEL

L70N

L100N

FUEL

Diesel

DISPLACEMENT cc

320

435

SPEED rpm

3000

CYLINDER

1 vertical

COOLING SYSTEM

Air

STARTING SYSTEM

Recoil

CONSUMPTION

CONSUMPTION at 75% of load L/h

1,0

1,3

TANK CAPACITY L

3,3

5,4

RUNNING TIME at 75% of load h

3,5

4,2

NOISE EMISSION

NOISE PRESSURE LEVEL at 7 m dB(A)

GUARANTEED SOUND POWER LEVEL LWA dB(A)

101

105

DIMENSIONS AND WEIGHT

LENGTH mm

760

WIDTH mm

540

HEIGHT mm

560

WEIGHT (dry) Kg

SOCKET TYPE

2 x SCHUKO

1 x SCHUKO

1 x 230V 16A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

ALTERNATOR AND SOCKET PROTECTION

ELECTRIC PROTECTION

IP 23

SOCKET PROTECTION

IP 54

IP 44

* Equipment only for stationary installations - COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

ES series

LONG RUN ENERGY

A class of Petrol generators designed specifically for intensive

operations where performance power is demanded by professional

users over an extended period of time.

GENERATING SET

ES3000

ES4000

ES5000

ES8000

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

5,0/6,3

6,6/8,3

(POWER COP) kW/kVA

4,3/5,4

5,6/7,0

SINGLE PHASE

(POWER LTP) kW/kVA

2,6/2,9

3,1/3,4

4,6/5,1

3,7/4,2

6,4/7,2

4,9/5,5

(POWER COP) kW/kVA

2,2/2,5

2,6/2,9

3,9/4,2

2,8/3,1

5,5/6,0

3,7/4,1

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

Frequency Hz

Power Factor cosФ

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

brand

Honda

model

GX160

GX200

GX270

GX390

FUEL

Petrol

Displacement cc

163

196

270

389

SPEED rpm

3000

Cylinder

1 inclined

Cooling system

Air

STARTING SYSTEM

Recoil

CONSUMPTION

Fuel consumption at 75% of load L/h

0,9

1,1

1,6

2,2

Fuel tank capacity L

Running time at 75% of load h

11,8

9,9

6,7

5,1

NOISE EMISSION

Guaranteed sound power level LWA dB(A)

Noise pressure level at 7 mt dB(A)

DIMENSIONS AND WEIGHT

Length mm

623

729

Width mm

409

500

Height mm

500

536

Weight (dry) Kg

SOCKET TYPE

2 x SCHUKO

1 x SCHUKO

1 x 230V 16A*

1 x SCHUKO

1 x 230V 16A*

1 x 230V 16A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

Alternator and socket protection

Electric protection

IP 23

Socket protection

IP 54

IP 44

* available also with SCHUKO configuration - COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

s series

THE COMPLETE PACKAGE

All the features of a top class generator: a powerful and economical engine,

a strong and modern design and a long-run easy filling fuel tank.

GENERATING SET

S5000

S8000

S12000

Single phase

Three phase

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

5,0/6,3

6,6/8,3

11,1/13,9

(POWER COP) kW/kVA

4,3/5,4

5,6/7,0

9,5/11,8

SINGLE PHASE

(POWER LTP) kW/kVA

4,8/5,3

3,7/4,2

6,4/7,2

4,9/5,5

10,7/11,9

8,3/9,2

(POWER COP) kW/kVA

4,0/4,1

2,8/3,1

5,5/6,0

3,7/4,1

9,1/10,0

6,3/6,9

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

230

400/230

Frequency Hz

Power Factor cosФ

0,9

0,8/0,9

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

brand

Honda

model

GX270

GX390

GX630

FUEL

Petrol

Displacement cc

270

389

688

SPEED rpm

3000

Cylinder

1 inclined

2 V angle

Cooling system

Air

STARTING SYSTEM / ELECTRIC CIRCUIT (12 Volt)

Electric/Recoil

Electric

CONSUMPTION

Fuel consumption at 75% of load L/h

1,6

2,2

2,1

3,9

Fuel tank capacity L

Running time at 75% of load h

11,0

8,4

6,1

NOISE EMISSION

Guaranteed sound power level LWA dB(A)

Noise pressure level at 7 mt dB(A)

DIMENSIONS AND WEIGHT

Length mm

842

960

Width mm

523

641

Height mm

557

667

Weight (dry) Kg

162

165

SOCKET TYPE

1 x SCHUKO

1 x 230V 32A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

1 x 230V 16A

2 x 230V 16A

1 x 230V 32A

1 x 400V 16A

ALTERNATOR AND SOCKET PROTECTION

Electric protection

IP 23

Socket protection

IP 44

COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

s series

The COMPLETE Diesel package

Showing the excellence of PRAMAC’ s professional equipment, this range

offers a robust package with a modern and economical Diesel engine.

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

5,5/6,9

8,2/10,3

(POWER COP) kW/kVA

4,5/5,6

7,0/8,8

SINGLE PHASE

(POWER LTP) kW/kVA

5,3/5,9

2,9/3,2

7,9/8,8

3,4/3,8

(POWER COP) kW/kVA

4,4/4,8

2,7/3,0

6,8/7,6

3,0/3,3

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

Frequency Hz

Power Factor cosФ

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

brand

Yanmar

Lombardini

model

L100N

25LD330

FUEL

Diesel

Displacement cc

435

654

SPEED rpm

3000

Cylinder

1 vertical

2 in line

Cooling system

Air

STARTING SYSTEM / ELECTRIC CIRCUIT (12 Volt)

Electric

CONSUMPTION

Fuel consumption at 75% of load L/h

1,4

2,0

Fuel tank capacity L

5,4

24,0

Running time at 75% of load h

3,9

12,0

NOISE EMISSION

Guaranteed sound power level LWA dB(A)

105

Noise pressure level at 7 mt dB(A)

DIMENSIONS AND WEIGHT

Length mm

830

960

Width mm

490

641

Height mm

570

667

Weight (dry) Kg

108

157

160

SOCKET TYPE

1 x SCHUKO

2 x SCHUKO

1 x SCHUKO

1 x 230V 16A

1 x 230V 32A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

ALTERNATOR AND SOCKET PROTECTION

Electric protection

IP 23

Socket protection

IP 44

Equipment only for stationary installations - COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

sp series

The complete

protection

A premium range with insulation monitoring

and Automatic Voltage Regulator as standard.

All panels and alternators featuring IP 54 protection.

GENERATING SET

SP8000

SP12000

Three phase

THREE PHASE

(POWER LTP) kW/kVA

7,1/8,8

11,1/13,8

(POWER COP) kW/kVA

5,4/6,8

9,4/11,8

SINGLE PHASE

(POWER LTP) kW/kVA

5,2/5,8

8,2/9,1

(POWER COP) kW/kVA

3,6/4,0

6,2/7,0

POWER SPECIFICATIONS

VOLTAGE Volt

400/230

Frequency Hz

Power Factor cosФ

0,8/0,9

ENGINE

brand

Honda

model

GX390

GX630

FUEL

Petrol

Displacement cc

389

688

SPEED rpm

3000

Cylinder

1 inclined

2 V angle

Cooling system

Air

STARTING SYSTEM / ELECTRIC CIRCUIT (12 Volt)

Electric/Recoil

Electric

CONSUMPTION

Fuel consumption at 75% of load L/h

1,9

3,9

Fuel tank capacity L

Running time at 75% of load h

9,3

6,1

NOISE EMISSION

Guaranteed sound power level LWA dB(A)

Noise pressure level at 7 mt dB(A)

DIMENSIONS AND WEIGHT

Length mm

842

960

Width mm

523

641

Height mm

557

667

Weight (dry)** Kg

113

170

SOCKET TYPE

1 x 230V 16A

3 x SCHUKO

1 x 400V 16A

1 x 400V 32A

ALTERNATOR AND SOCKET PROTECTION

Electric protection

IP 54

Socket protection

IP 54

** On electric version +3/8 Kg to add - COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

P inverter SERIES

THE ACCURATE ENERGY

The right power to supply equipment sensitive

to voltage surges.

P3000i

P4500i

GENERATING SET

P2000i

P3000i

P4500i

Single phase

THREE PHASE

(POWER LTP) kW/kVA

(POWER COP) kW/kVA

SINGLE PHASE

(POWER LTP) kW/kVA

1,65/1,65

2,80/2,80

4,30/4,30

(POWER COP) kW/kVA

1,35/1,35

2,50/2,50

3,80/3,80

POWER SPECIFICATIONS

VOLTAGE Volt

230

FREQUENCY Hz

POWER FACTOR cosФ

1,0

ENGINE

BRAND

Robin

MODEL

EH09-2

EX17

EX27

FUEL

Petrol

DISPLACEMENT cc

169

265

SPEED

variable

CYLINDER

1 vertical

1 inclined

COOLING SYSTEM

Air

STARTING SYSTEM

Recoil

Electric

CONSUMPTION

CONSUMPTION at 75% of load L/h

0,58

1,25

1,66

TANK CAPACITY L

3,5

RUNNING TIME at 75% of load h

6,0

8,6

7,7

NOISE EMISSION

NOISE PRESSURE LEVEL at 7 m dB(A)

GUARANTEED SOUND POWER LEVEL LWA dB(A)

DIMENSIONS AND WEIGHT

LENGTH mm

490

537

580

WIDTH mm

295

482

527

HEIGHT mm

445

583

618

WEIGHT (dry) Kg

SOCKET TYPE

2 x SCHUKO

Battery charger 12V 8,3A

ALTERNATOR AND SOCKET PROTECTION

ELECTRIC PROTECTION

IP 23

SOCKET PROTECTION

IP 54

IP 44

COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

P series

THE SILENT POWER (I)

The ideal generator for use in residential areas or outside normal

working hours. These generators are equipped with first class

components and complete instrumentation.

P4500

P9000

GENERATING SET

P4500

P6000

P6000s

P9000

Single phase

Three phase

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

5,5/6,9

8,2/10,3

(POWER COP) kW/kVA

4,5/5,6

7,0/8,8

SINGLE PHASE

(POWER LTP) kW/kVA

3,7/4,1

5,3/5,9

2,6/2,9

5,4/5,9

2,9/3,2

7,9/8,8

5,9/6,6

(POWER COP) kW/kVA

3,1/3,5

4,3/4,8

2,0/2,2

4,4/4,9

2,7/3,0

6,8/7,6

3,0/3,3

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

230

400/230

Frequency Hz

Power Factor cosФ

0,9

0,8/0,9

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

brand

Yanmar

Lombardini

model

L70N

L100N

25LD330

FUEL

Diesel

Displacement cc

320

435

654

SPEED rpm

3000

Cylinder

1 vertical

2 in line

Cooling system

Air

STARTING SYSTEM / ELECTRIC CIRCUIT (12 Volt)

Electric/Recoil

Electric

CONSUMPTION

Fuel consumption at 75% of load L/h

1,0

1,4

2,0

Fuel tank capacity L

Running time at 75% of load h

18,0

17,1

13,6

12,0

NOISE EMISSION

Guaranteed sound power level LWA dB(A)

Noise pressure level at 7 mt dB(A)

DIMENSIONS AND WEIGHT

Length mm

800

945

970

945

Width mm

520

595

580

595

Height mm

660

825

927

825

Weight (dry)** Kg

186

203

204

207

Socket type

1 x SCHUKO

1 x 230V 16A

2 x 230V 16A

1 x 230V 16A

2 x 230V 16A

1 x 230V 32A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

ALTERNATOR AND SOCKET PROTECTION

Electric protection

IP 23

Socket protection

IP 44

** On electric version +3/8 Kg to add - COP Continuous Power - LTP Maximum Power

PORTABLE Range / Gensets

p series

THE SILENT POWER (II)

Low noise level, AMF or RSS features and powerful, reliable Diesel

engines. These generators are ideal for domestic backup power supply

or professional use in residential areas.

P11000

P12000 Diesel

GENERATING SET

P11000

P12000

Single phase

Three phase

Single phase

Three phase

THREE PHASE

(POWER LTP) kW/kVA

8,5/10,6

12,6/15,8

11,1/13,9

(POWER COP) kW/kVA

8,0/10,0

8,8/11,0

9,5/11,8

SINGLE PHASE

(POWER LTP) kW/kVA

9,5/10,6

5,3/6,6

10,7/11,9

4,2/4,6

(POWER COP) kW/kVA

9,0/10,0

5,4/6,0

9,1/10,0

3,6/4,0

POWER SPECIFICATIONS

VOLTAGE Volt

230

400/230

230

400/230

Frequency Hz

Power Factor cosФ

0,9

0,8/0,9

0,9

0,8/0,9

ENGINE

brand

Yanmar

Honda

Hatz

Honda

model

3TNV70

GX630

2 G 40

GX630

FUEL

Diesel

Petrol

Diesel

Petrol

Displacement cc

854

688

997

688

SPEED rpm

3000

Cylinder

3 in line

2 V angle

2 in line

2 V angle

Cooling system

Water

Air

STARTING SYSTEM / ELECTRIC CIRCUIT (12 Volt)

Electric

CONSUMPTION

Fuel consumption at 75% of load L/h

3,0

4,1

2,3

4,1

Fuel tank capacity L

Running time at 75% of load h

8,0

5,9

7,5

5,9

NOISE EMISSION

Guaranteed sound power level LWA dB(A)

Noise pressure level at 7 mt dB(A)

DIMENSIONS AND WEIGHT

Length mm

1451

945

1270

945

Width mm

650

595

830

595

Height mm

975

825

920

825

Weight (dry) Kg

325

188

275

185

SOCKET TYPE

2 x 230V 16A

1 x 230V 16A

1 x SCHUKO

1 x 230V 16A

1 x SCHUKO

1 x 230V 32A

1 x 230V 16A

1 x 230V 32A

2 x 230V 16A

1 x 400V 16A

1 x 230V 32A

1 x 400V 16A

ALTERNATOR AND SOCKET PROTECTION

Electric protection

IP 23

Socket protection

IP 44

COP Continuous Power - LTP Maximum Power

PORTABLE Range / Power equipment

w series / PW serieS

MECHANIC WELDING REGULATION

Direct and Gearbox Transmission

WELDER GENERATORS

W220

WELDING PARAMETERS

Welding current A

40-220

Min/max welding VOLTAGE

21,6/28,8

Welding service at 60% A

170

MAX DIAMETER OF ELECTRODE

Rutile mm

Basic mm

Cellulose mm

THREE PHASE

POWER (LTP) kW/kVA

5,5/6,1

POWER (COP) kVA

5,2

SINGLE PHASE

HIGH PRESSURE WASHERS

PW240

PW3000

POWER (LTP) kW/kVA

2,4/2,7

POWER (COP) kVA

2,3

PUMP

POWER SPECIFICATIONS

Max pressure bar/psi

240/3500

200/2900

VOLTAGE Volt

400/230

Flow L/min

12,5

15,0

Frequency Hz

SPEED rpm

3400

1450

Power Factor cosФ

0,8/0,9

ENGINE

BRAND

Honda

Yanmar

BRAND

Honda

MODEL

GX390

L100N

MODEL

GX390

FUEL

Petrol

Diesel

FUEL

Petrol

Displacement cc

389

435

Displacement cc

389

Cylinder

1 inclined

1 vertical

SPEED rpm

3000

Cooling system

Air

Cylinder

1 inclined

STARTING SYSTEM / ELECTRIC CIRCUIT (12 Volt)

Recoil

Electric

Cooling system

Air

CONSUMPTION

STARTING SYSTEM

Recoil

Consumption at 75% of load L/h

2,0

1,5

CONSUMPTION

Tank capacity L

6,1

5,4

Consumption at 75% of load L/h

2,2

Running time at 75% of load h

3,0

3,6

Tank capacity L

6,1

NOISE EMISSION

Running time at 75% of load h

2,8

Noise level LWA dB(A)

103

108

NOISE EMISSION

Acoustic pressure at 7 m dB(A)

Noise level LWA dB(A)

DIMENSION AND WEIGHT

Acoustic pressure at 7 m dB(A)

Length mm

951

1040

DIMENSIONS AND WEIGHT

Width mm

765

590

Length mm

875

Height mm

655

790

Width mm

620

Weight (dry) Kg

117

Height mm

600

STANDARD EQUIPMENT, OPTIONS AND ACCESSORIES (x: Standard, o: Optional)

Weight (dry) Kg

Oil guard system

Socket Type

2:1 gear box

1 x SCHUKO

Direct drive

1 x 400V 16A

Chemical injection

ALTERNATOR AND SOCKET PROTECTION

Pressure hose

Electric protection

IP 23

Suction hose with strainer

Socket protection

IP 44

Inline filter

COP Continuous Power - LTP Maximum Power

PORTABLE Range / Power equipment

TG series PTO SHAFT GENERATORS

ENERGY FOR AGRICULTURE

These generators provide an economical way to supply electricity to any part of your

agricultural land. Using the pto shaft of a tractor, the TG class generator can produce

high quality power for any agricultural use.

PTO SHAFT GENERATORS

TG 12/3

TG 16/3

TG 20/3

TG 25/3

TG 25/15

TG 27/15

TG 30/15

TG 42/15

TG 48/15

TG 62/15

TG 72/15

THREE PHASE

(POWER COP) kVA

SINGLE PHASE

(POWER COP) kVA

8,5

14,7

16,7

21,6

25,2

POWER SPECIFICATIONS

VOLTAGE Volt

400/230

Frequency Hz

GEAR BOX REVOLUTION rpm

3000

1500

POWER (TRACTOR) kW/HP

22/30

29/40

37/50

44/60

48/65

51/70

74/100

88/120

103/140

118/160

REVOLUTION PTO SHAFT rpm

435

430

395

VOLTAGE REGULATION SYSTEM

Compound Compound Compound Compound

AVR

VOLTAGE ACCURACY

1,5%

0,5%

DIMENSIONS AND WEIGHT

Length mm

746

958

1110

Width mm

580

645

720

Height mm

958

1003

1322

Weight (dry) Kg

123

134

160

166

200

212

216

385

390

430

470

STANDARD EQUIPMENT, OPTIONS AND ACCESSORIES

(x: Standard, o: Optional)

MAGNETO THERMAL PROTECTION

differential protection

Volt/FREQUENCY METER

IP 44* PROTECTION

MIN-MAX VOLTAGE CONTROLER

SOCKET TYPE

1 x 230V 16A

1 x 230V 32A

1 x 400V 16A

1 x 400V 32A

1 x 400V 63A

1 x 400V 125A 1 x 400V 125A

ALTERNATOR AND SOCKET PROTECTION

Electric protection

IP 23

Socket protection

IP 44

* with IP 44 power is reduced by 10% - COP Continuous Power - LTP Maximum Power

PORTABLE Range / Power equipment

mp series MOTOR PUMPS

For Trash and

Clean Water

Whenever it is necessary to move large quantities

of water, whether during flooding or simply filling

a pond, these Petrol powered pumps can move it

quickly and efficiently.

Inlet, Outlet Pipes

MOTOR PUMPS

MP36-2

MP56-3

MP34-2

MP66-3

PUMP

Type

Semitrash

Trash

Head m

Flow L/min

600

930

700

1340

SPEED rpm

3600

Input/output diameter inch

MAX DIAMETER ALLOWED mm

ENGINE

BRAND

Honda

MODEL

GX120

GX160

GX240

FUEL

Petrol

Displacement cc

118

163

242

Cylinder

1 inclined

Cooling system

Air

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Recoil

CONSUMPTION

Consumption at 75% of load L/h

1,0

1,4

1,0

1,5

Tank capacity L

2,0

3,1

5,3

Running time at 75% of load h

2,0

2,2

3,1

3,5

NOISE EMISSION

Noise level LWA dB(A)

103

105

106

110

Acoustic pressure at 7 m dB(A)

DIMENSIONS AND WEIGHT

Length mm

437

477

520

690

Width mm

364

416

462

485

Height mm

399

466

481

537

Weight (dry) Kg

STANDARD EQUIPMENT, OPTION AND ACCESSORIES (x: Standard, o: Optional)

Oil guard system

3 jubilee pipe clips

2 threaded couplings

Filter

Spark plug tool

Inlet pipes 2”, 3” length 8/25 m

Outlet pipe 2”, 3” length 5/10/50/100 m

PORTABLE Range / Power equipment

LIGHT GLOBE & LIGHT TOWER lighting equipment

Powerful light

With a high luminosity power, the LIGHT GLOBE and LIGHT TOWER are the

innovative easy-to-use solutions for many activities: sport events, building

yards, night harvest, emergency needs.

LIGHT TOWER: Quick open/close system

LIGHT TOWER: Mast support and

LIGHT GLOBE: Protection grid (standard)

LIGHT GLOBE: Transportation case (standard)

for legs

four rings for lifting

GLOBE DIAMETER LIT UP AREA LUMEN VOLTAGE/FREQ MAST PROTECTION

LAMP

MAX WIND SPEED MAX HEIGHT OPERATION TEMPERATURE WEIGHT

V/Hz

LEVEL

W/type

Km/h

°C

LIGHT GLOBE 750 H

310

11400

230/50

Included

IP 54

750 W Halogen

2,8

-25/+45

LIGHT GLOBE 2.0 H

1500

54000

230/50

Optional

IP 54

2000 W Halogen

100

5,0

-25/+45

LIGHT GLOBE 1.0 HIT

120

3000

110000

230/50

Optional

IP 54

1000 W HIT*

100

5,0

- 25/+45

20*

VOLTAGE/

LAMP

LUMEN LIT UP AREA

LAMP

ELEVATION

MAX HEIGHT^OPERATION

FREQ

AUTONOMY

TEMPERATURE PROTECTIONWEIGHT

type

V/Hz

type

hours

°C

LEVEL

LIGHT TOWER 500Wx4 for Portable*

2000

38000

700

Halogen

230/50

Pneumatic

2000

-5/+130

IP 65

LIGHT TOWER 1000Wx4 for Portable*

4000

88000

1500

Halogen

230/50

Pneumatic

2000

-5/+130

IP65

LIGHT TOWER 400Wx6

2400

192000

2500

Metal Halide

400/50

Hydraulic

5000

9,0

-5/+130

IP 55

630

LIGHT TOWER 1500Wx6

9000

200000

1200

Halogen

400/50

Hydraulic

4000

9,0

-5/+130

IP 55

630

LSW 6K**

4000

404000

up to 4000

Metal Halide

230/50

Manual

10000

9,2

-5/+130

IP 55

680

LSW 9

4000

360000

4200

Metal Halide

230/50

Hydraulic

9000

9,0

-5/+130

IP 66

970

* Elevation type (Compressed air) | Telescopic shaft sliding sections (3) - ** Extra EU

GENSETS PRODUCTION PLANTS

ENERGY fOR ALL YOUR NEEDS

PRAMAC S.p.A.

Casole d’Elsa (SIENA) - Italy

Production capacity

2.000 stationary generators / year up to 3.000 kVA

Surface: 40.000 sm

Approx. 130 employees

PRAMAC FRANCE S.A.S.

St. Nizier sous Charlieu (LYON) - France

Production capacity

80.000 portable generators / year

Surface: 20.000 sm

Approx. 45 employees

PRAMAC IBERICA S.A.U.

Balsicas (Murcia) - Spain

Inaugurated in january 2003

Production capacity

3.000 portable generators/year

18.000 stationary generators / year up to 250 kVA

Surface: 22.000 sm

Approx. 150 employees

PRAMAC AMERICA LLC

Kearney (Nebraska) - USA

Starting activity in Kearney August 1st 2008

Production capacity

300.000 units / year

(80.000 on current labor force)

Surface: 20.000 sm

Over 50 employees

PRAMAC FU LEE (Foshan) Power Equipment CO. LTD.

Shunde (GUANGDONG) - China

Inaugurated in january 2006

Production capacity

50.000 portable generators / year

2.000 stationary generators / year up to 700 kVA

Surface: 16.000 sm

Approx. 60 employees

STATIONARY RANGE / OPEN VERSION

gbA series

Energy for

all your needs

The GBA series offers the simplest way to fulfill particular

power demands. The high quality components make

these generators very reliable and easy to use. They are

also ideal for starting and powering motor pumps.

Engine protection unit and remote start/stop

Rated battery capacity

under request

Generating set

GBA7L

GBA12L

GBA17L

Stand by power LTP kW/kVA

5,3 / 6,7

8,8 / 11,0

14,1 / 17,6

Prime power PRP kW/kVA

4,9 / 6,1

8,0 / 10,0

12,6 / 15,8

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Lombardini

MODEL

4LD820

9LD 625

11LD6263L

Fuel

Diesel

Cooling system

Air

Number and disposition of cylinders

1 in line

2 in line

3 in line

Displacement cc

817

1248

1870

Aspiration

Natural

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

6,6

10,7

16,7

Prime power PRP kW

6,0

9,7

14,7

Fuel consumption at 75% / 100% PRP L/h

1,5 / 2,1

2 / 2,6

3,1 / 4,2

ALTERNATOR

Type

With brushes

Poles

VOLTAGE regulation system

Compound

OVERALL DIMENSIONS AND WEIGHT

Length mm

1226

Width mm

700

Height mm

1132

Weight Kg

232

244

340

Fuel tank capacity L

7,0

10,0

51,0

RUNNING TIME at 75% / 100% PRP h

4,5 / 3,4

5,1 / 3,8

16,5 / 12,1

STATIONARY RANGE / OPEN VERSION

gbW series

power and versatility

The GBW Series offers reliable and powerful machines designed for

professional use on construction sites and other industrial

applications. With an excellent performance and easy installation

they can be used either to support electricity

mains failure or isolated locations.

Wide range of accessories

Analogue instrumentation and sockets

Support legs welded to baseframe

Water cooling sets

Generating set

GBW10y

GBW15y

GBW22y

GBW30y

GBW45y

Stand by power LTP kW/kVA

7,5 / 9,3

11,4 / 14,3

15,5 / 19,4

26,0 / 32,5

36,7 / 45,9

Prime power PRP kW/kVA

6,8 / 8,5

10,4 / 13,0

14,1 / 17,6

24,4 / 30,5

33,4 / 41,8

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Yanmar

MODEL

3TNV76

3TNV88

4TNV88

4TNV98

4TNV98T

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

Displacement cc

1116

1642

2190

3319

Aspiration

Natural

Turbo

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

9,0

13,6

18,0

34,1

41,4

Prime power PRP kW

8,2

12,3

16,4

30,7

37,7

Fuel consumption at 75% / 100% PRP L/h

2,0 / 2,7

2,8 / 3,8

3,7 / 4,9

5,8 / 7,8

7,9 / 10,5

ALTERNATOR

Type

With brushes

Brushless

Poles

VOLTAGE regulation system

Compound

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

1600

2000

Width mm

870

920

Height mm

875

950

1000

1100

Weight Kg

250

390

507

560

611

Fuel tank capacity L

RUNNING TIME at 75% / 100% PRP h

25,6 / 19,2

18,0 / 13,5

13,7 / 10,3

8,8 / 6,6

6,5 / 4,9

STATIONARY RANGE / OPEN VERSION

Generating set

GBW10P

GBW15p

GBW22p

GBW30p ⁽¹⁾

GBW45p ⁽¹⁾

Stand by power LTP kW/kVA

7,7 / 9,7

11,3 / 14,1

17,5 / 21,8

26,0 / 32,5

38,4 / 48,0

Prime power PRP kW/kVA

7,0 / 8,7

10,2 / 12,7

15,8 / 19,8

24,4 / 30,5

36,6 / 45,7

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Perkins

MODEL

403D-11G

403D-15G

404D-22G

1103A-33G

1103A-33TG1

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

3 in line

Displacement cc

1131

1496

2216

3300

Aspiration

Natural

Turbo

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

9,3

13,3

20,3

30,4

45,6

Prime power PRP kW

8,4

12,0

18,4

27,7

41,3

Fuel consumption at 75% / 100% PRP L/h

2,6 / 2,0

2,7 / 3,6

3,8 / 5,1

5,1 / 6,8

8,2 / 10,7

ALTERNATOR

Type

With brushes

Brushless

Poles

VOLTAGE regulation system

Compound

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

1226

1600

2000

Width mm

700

870

920

Height mm

1132

950

1000

1100

Weight Kg

385

425

495

700

785

Fuel tank capacity L

RUNNING TIME at 75% / 100% PRP h

25,8 / 19,8

18,6 / 14,2

13,6 / 10,2

9,4 / 7,2

6,2 / 4,8

(1)

This Generator is normally intended to be used for stationary application only. In this case, its engine would not have to comply with EU 2004/26/EC Stage IIIA (EU 2011) Directive

(no need for subsequent modifications and/or integrations).

STATIONARY RANGE / OPEN VERSION

gsA series

CONSTANT

POWER SUPPLY

The GSA generators provide peace-of-mind:

with a greatly extended running time, these sets

offer a professional solution against mains power

failure, maintaining a constant power supply.

Generating set

GSA22d

GSA30d

GSA42d ⁽¹⁾

GSA65d ⁽¹⁾

Stand by power LTP kW/kVA

17,2 / 21,5

25,6 / 31,9

33,7 / 42,1

50,6 / 63,2

Prime power PRP kW/kVA

16,4 / 20,5

24,3 / 30,4

32,8 / 41,0

49,7 / 62,1

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Deutz

MODEL

F3L2011

F4L2011

F4L912

F6L912

Cooling system

Air

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

6 in line

Displacement cc

2330

3110

3770

5650

Aspiration

Natural

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

20,0

29,0

38,0

56,0

Prime power PRP kW

19,0

27,6

37,0

55,0

Fuel consumption at 75% / 100% PRP L/h

4,1 / 5,3

5,7 / 7,5

7,3 / 10,0

10,9 / 15,0

ALTERNATOR

Type

With brushes

Brushless

Poles

VOLTAGE regulation system

Compound

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

1400

1800

2200

Width mm

750

1000

Height mm

1700

1710

1620

Weight Kg

510

663

776

954

Fuel tank capacity L

240

RUNNING TIME at 75% / 100% PRP h

22,4 / 17,0

15,9 / 12,1

12,5 / 9,1

22,0 / 16,0

(1)

This Generator is normally intended to be used for stationary application only. In this case, its engine would not have to comply with EU 2004/26/EC Stage IIIA (EU 2011) Directive

(no need for subsequent modifications and/or integrations).

STATIONARY RANGE / OPEN VERSION

gsl series

An alternative

power supply

Great performance from these oil cooled engine

generators, offering reliable power with easy installation.

The GSL series is perfect for locations not

connected to a mains power supply.

Generating set

GSL22d

GSL30d

GSL42d

GSL65d

Stand by power LTP kW/kVA

17,2 / 21,5

25,6 / 31,9

33,1 / 41,4

50,6 / 63,2

Prime power PRP kW/kVA

16,4 / 20,5

24,3 / 30,4

31,6 / 39,5

48,8 / 61,0

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Deutz

MODEL

F3M2011

F4M2011

BF4M2011

BF4M2011C

Cooling system

Oil

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

Displacement cc

2330

3110

Aspiration

Natural

Turbo

Turbo, CAC

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

20,0

29,0

37,4

56,0

Prime power PRP kW

19,0

27,6

35,6

54,0

Fuel consumption at 75% / 100% PRP L/h

4,1 / 5,8

5,7 / 8,0

9,4 / 12,5

10,4 / 14,1

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

1800

2000

Width mm

750

Height mm

1720

1520

Weight Kg

510

714

761

881

Fuel tank capacity L

RUNNING TIME at 75% / 100% PRP h

22,5 / 15,6

16,0 / 11,3

9,7 / 7,3

8,7 / 6,5

STATIONARY RANGE / OPEN VERSION

gsw series

Energy for public

and industrial USES

The GSW series is available with a range of accessories providing a versatile

solution to a variety of applications.

This family of generators offers the best performance under the most difficult and

variable operating conditions.

Ideal for major industrial areas that need an extra power source.

Availability of different cubicle solutions

Fuel water filter separator

Moving and rotating parts protection

Manual oil Drain Pump

GENERATING SET

GSW65P

GSW80P

GSW110P

GSW150P ⁽¹⁾

GSW155P

GSW165P ⁽¹⁾

GSW170P

GSW210P

STAND BY POWER LTP kW/kVA

53,5/67,0

66,0/83,0

91,7/114,7

114,4/143,0

131,2/164,0

163,1/203,8

PRIME POWER PRP kW/kVA

48,6/60,7

62,4/78,0

83,1/103,9

109,6/137,0

120,5/150,6

120,6/150,8

147,2/184,0

Voltage Volt/ FREQUENCY Hz

400/50

Phases

ENGINE

BRAND

Perkins

Model

1103A-33TG2

1104A-44TG2

1104C-44TAG2

1006 TAG

1106C-E66TAG2

1006 TAG2

1106C-E66TAG3

1106C-E66TAG4

Cooling system

Water

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

3 in line

4 in line

6 in line

Displacement cc

3300

4400

4410

5990

6600

5990

6600

Aspiration

Turbocharged

Turbo CAC

STARTING SYSTEM/ELECTRIC CIRCUIT (Volt)

Electric/12

Speed rpm

1500

SPEED GOVERNOR

Mechanical

Electronic

STAND BY POWER LTP kW

59,3

79,2

99,5

133,5

133

143

143,9

175,9

PRIME POWER PRP kW

53,8

71,9

90,1

120,9

119,5

129,3

129,4

158,8

Fuel consumption at 75% / 100% PRP L/h

10,42/13,9

13,43/17,9

18,0/22,6

23,9/30,8

24,2/30,6

31,5/41,0

26,0/33,1

31,2/40,2

ALTERNATOR

Type

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

2200

2600

Width mm

1000

Height mm

1743

Weight Kg

909

964

1170

1417

1623

1451

1757

2030

Fuel tank capacity L

209

240

250

400

RUNNING TIME at 75% / 100% PRP h

20,0/15,0

18,1/13,6

13,3/10,6

10,5/8,1

10,2/8,1

7,9/6,1

9,6/7,5

12,8/9,9

(1)

This Generator is normally intended to be used for stationary application only. In this case, its engine would not have to comply with EU 2004/26/EC Stage IIIA (EU 2011) Directive

(no need for subsequent modifications and/or integrations).

STATIONARY RANGE / OPEN VERSION

GENERATING SET

GSW65I

GSW80I

GSW110I

GSW145I

GSW170I

GSW220I

STAND BY POWER LTP kW/kVA

53,1/66,4

66,0/82,4

88,7/110,9

112,2/140,2

131,2/164,0

176,0/220,0

PRIME POWER PRP kW/kVA

48,2/60,2

60,0/74,1

80,7/100,8

102,0/127,5

126,4/158,0

162,2/202,8

VOLTAGE Volt / FREQUENCY Hz

400/50

PHASES

ENGINE

BRAND

FPT

MODEL

NEF45SM1A

NEF45SM2A

NEF45TM2A

NEF67SM1A

NEF67TM3

NEF67TE2A

COOLING SYSTEM

Water

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

4 in line

6 in line

DISPLACEMENT cc

4500

6700

ASPIRATION

Turbo

Turbo CAC

Turbo

Turbo CAC

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

SPEED rpm

1500

SPEED GOVERNOR

Mechanical

Electronic

STAND BY POWER LTP kW

58,9

72,7

96,2

121,0

152,0

193,0

PRIME POWER PRP kW

53,3

66,1

87,5

110,0

137,7

175,0

Fuel consumption at 75% / 100% PRP L/h

10,3 / 13,7

12,8 / 17,2

16,3 / 22,1

21,5 / 28,2

27,1 / 35,6

33,5 / 44,0

ALTERNATOR

Type

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

2200

2600

Width mm

1000

Height mm

1620

1743

1700

Weight Kg

1123

1139

1310

1441

1505

1590

Fuel tank capacity L

248

RUNNING TIME at 75% / 100% PRP h

23,4 / 17,5

18,8 / 14,0

14,7 / 10,9

11,6 / 8,9

9,2 / 7,0

7,5 / 5,7

STATIONARY RANGE / OPEN VERSION

gsw series

Power in isolation

A continuous power supply, provided with high power

output and extended running time, makes this range

of generators the most suitable for powering sites

not connected to a mains power supply.

This range is also ideal for running lighting systems

during power failures.

Well balanced engine block 6 in line cylinders

Terminal board load connection

Electronic card

Generating set

GSW110V

GSW150V

GSW170V

GSW220V

GSW275v

GSW330v

Stand by power LTP kW/kVA

90,4/112,9

114,4/143,0

131,2/164,0

176,0/220,0

220,0/275,0

264,0/330,0

Prime power PRP kW/kVA

81,1/101,4

103,9/129,8

125,4/156,7

162,1/202,7

198,9/248,7

252,0/315,0

VOLTAGE Volt / Frequency Hz

400/50

400 / 50

Phases

ENGINE

brand

Volvo

model

TAD531GE

TAD532GE

TAD731GE

TAD733GE

TAD734GE

TAD941GE

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

4 in line

6 in line

Displacement cc

4760

7150

9360

Aspiration

Turbocharged intercooler

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Electric / 24

Speed rpm

1500

Speed governor

Mechanical

Electronic

Mechanical

Electronic

stand by power LTP kW

98,0

125,0

149,5

194,9

238,0

310,0

Prime power PRP kW

88,0

112,0

134,5

174,9

213,0

281,0

Fuel consumption at 75% / 100% PRP L/h

18,6 / 24,4

22,9 / 30,6

26,8 / 35,3

34,9 / 46,5

41,5 / 58,0

51,0 / 67,8

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

2200

2650

3300

Width mm

1000

1100

1180

1400

Height mm

1620

1965

1844

1887

Weight Kg

1433

1491

1796

2238

2177

2580

Fuel tank capacity L

340

400

636

RUNNING TIME at 75% / 100% PRP h

18,3 / 14,0

14,9 / 11,1

12,7 / 9,6

9,7 / 7,3

9,6 / 6,9

12,5 / 9,4

STATIONARY RANGE / OPEN VERSION

Generating set

GSW415v

GSW450v

GSW510v

GSW560v

GSW590v

GSW630v

GSW705v

Stand by power LTP kW/kVA

332,9/416,1

350,0/437,0

404,7/505,9

436,8/546,0

480,8/601,0

505,4/631,8

562,0/702,5

Prime power PRP kW/kVA

303,9/379,8

331,0/413,7

364,3/455,4

403,7/504,7

456,9/571,0

457,4/571.7

505,4/631,8

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

brand

Volvo

model

TAD1343GE

TAD1344GE

TAD1345GE

TAD1641GE

TAD1642GE

TWD1643GE

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

6 in line

Displacement cc

12780

16120

Aspiration

Turbocharged intercooler

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 24

Speed rpm

1500

Speed governor

Electronic

stand by power LTP kW

356

389

431

473

536

596

Prime power PRP kW

325

354

388

430

485

536

Fuel consumption at 75% / 100% PRP L/h

58,1 / 76,6

64,4 / 84,1

70,4 / 92,9

77,6 / 104,5

87,5 / 118,7

87,6 / 118,7

97,4 / 131,0

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

3300

3500

3800

Width mm

1400

1500

1670

Height mm

1917

2120

2320

Weight Kg

3050

3180

3467

3620

3680

4590

Fuel tank capacity L

636

RUNNING TIME at 75% / 100% PRP h

10,9 / 8,3

9,9 / 7,6

9,0 / 6,8

8,2 / 6,1

7,3 / 5,5

6,5 / 4,9

STATIONARY RANGE / OPEN VERSION

gsw series

Power in isolation

A continuous power supply, provided with high power

output and extended running time, makes this range

of generators the most suitable for powering sites

not connected to a mains power supply.

This range is also ideal for running lighting systems

during power failures.

GENERATING SET

GSW310m

GSW330m

GSW405m

GSW440m

GSW515m

GSW570m

GSW665m

GSW730m

Standby Power LTP kW/kVA

247,6/309,5

264,0/330,0

325,8/407,2

349,6/437,0

406,6/508,2

450,3/562,9

527,1/658,9

581,8/727,3

Prime Power PRP kW/kVA

224,2/280,2

247,6/309,4

294,5/368,2

325,8/407,2

368,1/460,1

407,9/509,9

478,1/597,6

527,1/658,9

VOLTAGE Volt / Frequency Hz

400/50

Phases

ENGINE

Brand

MTU

Model

6R1600G70F

6R1600G80F

8V1600G70F

8V1600G80F

10V1600G70F

10V1600G80F

12V1600G70F

12V1600G80F

Cooling System

Water

Fuel

Diesel

Number and disposition of cylinders

6 in line

8 V angle

10 V angle

12 V angle

Displacement cc

10500

14000

17500

21000

Aspiration

Turbocharged intercooler

Starting system / Electric circuit (Volt)

Electric / 24

Speed rpm

1500

Speed governor

Electronic

Stand by Power LTP kW

264

291

348

384

433

478

559

617

Prime Power PRP kW

239

264

315

348

392

433

507

559

Fuel consumption at 75% / 100% PRP L/h

44,7/58,1

48,6/63,6

63,4/81,3

62,1/82,7

78,4/109,5

76,5/105,1

98,1/131,6

106,0/142,6

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

3300

3800

Width mm

1400

1800

1670

Height mm

2100

2120

2320

weight Kg

2920

3514

4658

4811

4994

5200

Fuel tank capacity L

636

Running time at 75% / 100% PRP h

14,2/10,9

13,1/10,0

10,0/7,8

10,2/7,7

8,1/5,8

8,3/6,1

6,5/4,8

6,6/4,5

STATIONARY RANGE / SOUNDPROOF VERSION

gbw series

FRIENDLY GENERATION

This range has optimized features specially focused to meet the needs of

low investment applications. Generators have reduced dimensions and weight

making them easy to transport and store. This range could be also used as

rental equipment.

Generating set

GBW10y

GBW15y

GBW22y

GBW10P

GBW15p

GBW22p

Stand by power LTP kW/kVA

7,5 / 9,3

11,4 / 14,3

15,5 / 19,4

7,7 / 9,7

11,3 / 14,1

17,5 / 21,8

Prime power PRP kW/kVA

6,8 / 8,5

10,4 / 13,0

14,1 / 17,6

7,0 / 8,7

10,2 / 12,7

15,8 / 19,8

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Yanmar

Perkins

MODEL

3TNV76

3TNV88

4TNV88

403D-11G

403D-15G

404D-22G

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

3 in line

4 in line

Displacement cc

1116

1642

2190

1131

1496

2216

Aspiration

Natural

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

9,0

13,6

18,0

9,3

13,3

20,3

Prime power PRP kW

8,2

12,3

16,4

8,4

12,0

18,4

Fuel consumption at 75% / 100% PRP L/h

2,0 / 2,7

2,8 / 3,8

3,7 / 4,9

2,6 / 2,0

2,7 / 3,6

3,8 / 5,1

ALTERNATOR

Type

With brushes

Poles

VOLTAGE regulation system

Compound

OVERALL DIMENSIONS AND WEIGHT

Length mm

1646

Width mm

870

Height mm

1061

Weight Kg

460

430

560

460

550

565

Fuel tank capacity L

RUNNING TIME at 75% / 100% PRP h

25,6 / 19,2

18,0 / 13,5

13,7 / 10,3

25,8 / 19,8

18,7 / 14,1

12,8 / 9,7

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

STATIONARY RANGE / SOUNDPROOF VERSION

gSw series

COMPACT ENERGY

This series provides the most professional way

to fulfill small power requirements

with the highest reliability and excellent performance.

Most popular range for residential areas

and telecommunication sites.

Generating set

GSW10y

GSW15y

GSW22y

GSW10p

GSW15p

GSW22p

Stand by power LTP kW/kVA

7,7/9,7

11,6/14,5

15,7/19,7

8,0/10,0

11,5/14,3

17,2/21,5

Prime power PRP kW/kVA

7,0/8,8

10,6/13,2

14,3/17,9

7,2/9,0

10,3/12,9

16,1/20,1

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

brand

Yanmar

Perkins

model

3TNV76

3TNV88

4TNV88

403D-11G

403D-15G

404D-22G

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

3 in line

4 in line

Displacement cc

1116

1642

2190

1131

1496

2215

Aspiration

Natural

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

9,0

13,6

18,0

9,3

13,3

20,3

Prime power PRP kW

8,2

12,3

16,4

8,4

18,3

Fuel consumption at 75% / 100% PRP L/h

2,0 / 2,7

2,9 / 3,8

3,7 / 4,9

2,6/2,0

2,7 / 3,6

4,0 / 5,3

ALTERNATOR

Type

Brushless

With brushes

Brushless

Poles

VOLTAGE regulation system

Electronic

Compound

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

1800

Width mm

850

Height mm

1261

1260

1261

Weight Kg

515

597

653

730

639

692

Fuel tank capacity L

RUNNING TIME at 75% / 100% PRP h

31,9 / 24,0

22,6 / 16,9

17,3 / 15,0

25,8/19,8

25,0 / 18,7

17,0 / 12,8

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

STATIONARY RANGE / SOUNDPROOF VERSION

gSw series

PROFESSIONAL ENERGY

This range of generators is suitable for any applications;

low noise, security, greatly extended running time and

versatility make GSW series the perfect choice for the

business.

Control panel behind lockable door

Stacking option while warehousing

Generating set

GSW30y

GSW45y

GSW30p ⁽¹⁾

GSW45p ⁽¹⁾

Stand by power LTP kW/kVA

26,0/32,5

36,7/45,9

26,0/32,5

38,4/48,0

Prime power PRP kW/kVA

24,4/30,5

33,4/41,8

24,4/30,5

36,6/45,7

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

brand

Yanmar

Perkins

model

4TNV98

4TNV98T

1103A-33G

1103A-33TG1

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

4 in line

3 in line

Displacement cc

3319

3300

Aspiration

Natural

Turbo

Natural

Turbo

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

34,1

41,4

30,4

45,6

Prime power PRP kW

30,7

37,7

27,7

41,3

Fuel consumption at 75% / 100% PRP L/h

6,1 / 8,1

8,7 / 11,6

5,4 / 7,1

8,2 / 10,7

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

2000

Width mm

920

Height mm

1310

Weight Kg

765

815

929

977

Fuel tank capacity L

RUNNING TIME at 75% / 100% PRP h

11,0 / 8,3

7,9 / 5,8

13,3 / 7,9

8,7 / 6,5

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

(1)

This Generator is normally intended to be used for stationary application only. In this case, its engine would not have to comply with EU 2004/26/EC Stage IIIA (EU 2011) Directive

(no need for subsequent modifications and/or integrations).

STATIONARY RANGE / SOUNDPROOF VERSION

gSL series

THE MULTIPURPOSE

GENERATOR

This range has been designed to meet particular market needs. The most suitable

application is on construction sites, where durability and reliability are required

to supply constant power to applications such as lighting, cranes, concrete

mixers and conveyor belts. With low noise emissions, they are also

suitable for open air activities, such as shows or sporting events.

Integrated oil cooling system

Analogue instrumentation and sockets

*MCP manual control panel with 5 sockets

(GSL 65 optional)

Generating set

GSL22d

GSL30d

GSL42d

GSL65d

Stand by power LTP kW/kVA

17,2 / 21,5

25,6 / 31,9

33,1 / 41,4

50,6 / 63,2

Prime power PRP kW/kVA

16,4 / 20,5

24,3 / 30,4

31,6 / 39,5

48,8 / 61,0

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

BRAND

Deutz

MODEL

F3M2011

F4M2011

BF4M2011

BF4M2011C

Cooling system

Oil

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

Displacement cc

2330

3110

Aspiration

Natural

Turbo

Turbo, CAC

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Speed rpm

1500

Speed governor

Mechanical

stand by power LTP kW

20,0

29,0

37,4

56,0

Prime power PRP kW

19,0

27,6

35,6

54,0

Fuel consumption at 75% / 100% PRP L/h

4,1 / 5,8

5,7 / 8,0

9,4 / 12,5

10,4 / 14,1

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

2000

2285

Width mm

920

Height mm

1310

Weight Kg

690

760

824

981

Fuel tank capacity L

209

RUNNING TIME at 75% / 100% PRP h

16,6 / 11,7

11,9 / 8,5

7,2 / 5,4

20,0 / 14,8

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

STATIONARY RANGE / SOUNDPROOF VERSION

gsw series

TOTAL ENERGY

Compliant with noise and safety regulations, this middle

power rated range is designed to meet every kind of application

without any specific or special requirements.

Lockable door handles

Fuel filter

Generating set

GSW65p

GSW80P

GSW110p

GSW150p ⁽¹⁾

GSW155p

GSW165p ⁽¹⁾

GSW170p

GSW210p

Stand by power LTP kW/kVA

53,5/67,0

66,0/83,0

91,7/114,7

114,4/143,0

131,2/164,0

163,1/203,8

Prime power PRP kW/kVA

48,6/60,7

62,4/78,0

83,1/103,9

109,6/137,0

120,5/150,6

120,6/150,8

147,2/184,0

VOLTAGE Volt / Frequency Hz

400/50

Phases

ENGINE

brand

Perkins

model

1103A-33TG2

1104A-44TG2

1104C-44TAG2

1006 TAG

1106C-E66TAG2

1006 TAG2

1106C-E66TAG3

1106C-E66TAG4

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

3 in line

4 in line

6 in line

Displacement cc

3300

4400

4410

5990

6600

5990

6600

Aspiration

Turbocharged

Turbo CAC

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric/12

Speed rpm

1500

Speed governor

Mechanical

Electronic

stand by power LTP kW

59,3

79,2

99,5

133,5

133

143

143,9

175,9

Prime power PRP kW

53,8

71,9

90,1

120,9

119,5

129,3

129,4

158,8

Fuel consumption at 75% / 100% PRP L/h

13,9/10,42

17,9/13,43

22,6/18,0

30,8/23,9

30,6/24,2

41,0/31,5

33,1/26,0

40,2/31,2

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

2285

2400

3000

3414

3000

3414

Width mm

920

1000

1150

1338

1150

1338

Height mm

1500

1530

1740

1768

1740

1800

1768

Weight Kg

1085

1144

1400

1961

1942

1935

2038

2138

Fuel tank capacity L

209

340

RUNNING TIME at 75% / 100% PRP h

20,1 / 15,0

15,6 / 11,7

11,6 / 9,2

14,2 / 11,0

14,0 / 11,1

10,8 / 8,3

13,1 / 10,3

10,9 / 8,5

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

(1)

This Generator is normally intended to be used for stationary application only. In this case, its engine would not have to comply with EU 2004/26/EC Stage IIIA (EU 2011) Directive

(no need for subsequent modifications and/or integrations).

STATIONARY RANGE / SOUNDPROOF VERSION

gsw series

SILENT POWER

FOR PUBLIC AND

INDUSTRIAL USES

Low noise emissions (conforming to directive 2009/14/EC, related to

environmental noise emissions), conformity to gas emission laws and

high security (lockable panels, fireproof canopy) make these sets ideal

for any public or industrial applications.

Muffler rain cap

Fireproof noise attenuation material

Fuel water filter separator

Generating set

GSW110V

GSW150V

GSW170V

GSW220V

GSW275v

GSW330v

Stand by power LTP kW/kVA

90,4/112,9

114,4/143,0

131,2/164,0

176,0/220,0

220,0/275,0

264,0/330,0

Prime power PRP kW/kVA

81,1/101,4

103,9/129,8

125,4/156,7

162,1/202,7

198,9/248,7

252,0/315,0

VOLTAGE Volt / Frequency Hz

400/50

400 / 50

Phases

ENGINE

brand

Volvo

model

TAD531GE

TAD532GE

TAD731GE

TAD733GE

TAD734GE

TAD941GE

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

4 in line

6 in line

Displacement cc

4760

7150

9360

Aspiration

Turbocharged intercooler

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

Electric / 24

Speed rpm

1500

Speed governor

Mechanical

Electronic

Mechanical

Electronic

stand by power LTP kW

98,0

125,0

149,5

194,9

238,0

310,0

Prime power PRP kW

88,0

112,0

134,5

174,9

213,0

281,0

Fuel consumption at 75% / 100% PRP L/h

18,6 / 24,4

22,9 / 30,6

26,8 / 35,3

34,9 / 46,5

41,5 / 58,0

51,0 / 67,8

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

3000

3414

3951

Width mm

1150

1338

1438

Height mm

1770

1768

2095

Weight Kg

1734

1821

2224

2540

2990

3200

Fuel tank capacity L

340

636

RUNNING TIME at 75% / 100% PRP h

18,3 / 14,0

14,9 / 11,1

12,7 / 9,6

9,7 / 7,3

15,3 / 11,0

12,5 / 9,4

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

STATIONARY RANGE / SOUNDPROOF VERSION

Generating set

GSW415v

GSW450v

GSW510v

GSW560v

GSW590v

GSW630v

GSW705v

Stand by power LTP kW/kVA

332,9/416,1

350,0/437,0

404,7/505,9

436,8/546,0

480,8/601,0

505,4/631,8

562,0/702,5

Prime power PRP kW/kVA

303,9/379,8

331,0/413,7

364,3/455,4

403,7/504,7

456,9/571,0

457,4/571.7

505,4/631,8

VOLTAGE Volt / Frequency Hz

400 / 50

Phases

ENGINE

brand

Volvo

model

TAD1343GE

TAD1344GE

TAD1345GE

TAD1641GE

TAD1642GE

TWD1643GE

Cooling system

Water

Fuel

Diesel

Number and disposition of cylinders

6 in line

Displacement cc

12780

16120

Aspiration

Turbocharged intercooler

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 24

Speed rpm

1500

Speed governor

Electronic

stand by power LTP kW

356

389

431

473

536

596

Prime power PRP kW

325

354

388

430

485

536

Fuel consumption at 75% / 100% PRP L/h

58,1 / 76,6

64,4 / 84,1

70,4 / 92,9

77,6 / 104,5

87,5 / 118,7

87,6 / 118,7

97,4 / 131,0

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONS AND WEIGHT

Length mm

3951

4400

4700

Width mm

1438

1560

1670

Height mm

2095

2250

2430

Weight Kg

3671

4100

4495

4888

4945

5490

Fuel tank capacity L

636

RUNNING TIME at 75% / 100% PRP h

10,9 / 8,3

9,9 / 7,6

9,0 / 6,8

8,2 / 6,1

7,3 / 5,4

6,5 / 4,9

Noise pressure level at 7 mt dB(A)

Guaranteed sound power level LWA dB(A)

105

STATIONARY RANGE / SOUNDPROOF VERSION

gsw series

SUITABLE FOR SPECIFIC

APPLICATIONS

These generators are designed for stand by applications, and fulfill the

demand for “silent” power. Sturdy and reliable, like all PRAMAC

machines, the “silent” power is guaranteed to fully conform to

directive 2009/14/EC on environmental noise emissions.

GENERATING SET

GSW65I

GSW80I

GSW110I

GSW145I

GSW170I

GSW220I

STAND BY POWER LTP kW/kVA

53,1/66,4

66,0/82,4

88,7/110,9

112,2/140,2

131,2/164,0

176,0/220,0

PRIME POWER PRP kW/kVA

48,2/60,2

60,0/74,1

80,7/100,8

102,0/127,5

126,4/158,0

162,2/202,8

VOLTAGE Volt / FREQUENCY Hz

400/50

PHASES

ENGINE

BRAND

FPT

MODEL

NEF45SM1A

NEF45SM2A

NEF45TM2A

NEF67SM1A

NEF67TM3

NEF67TE2A

COOLING SYSTEM

Water

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

4 in line

6 in line

DISPLACEMENT cc

4500

6700

ASPIRATION

Turbo

Turbo CAC

Turbo

Turbo CAC

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 12

SPEED rpm

1500

SPEED GOVERNOR

Mechanical

Electronic

STAND BY POWER LTP kW

58,9

72,7

96,2

121,0

152,0

193,0

PRIME POWER PRP kW

53,3

66,1

87,5

110,0

137,7

175,0

FUEL CONSUMPTION at 75% / 100% PRP L/h

10,3 / 13,7

12,8 / 17,2

16,3 / 22,1

21,5 / 28,2

27,1 / 35,6

33,5 / 44,0

ALTERNATOR

TYPE

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

LENGTH mm

2400

3000

3400

WIDTH mm

1000

1150

1250

HEIGHT mm

1546

1771

1780

WEIGHT kg

1.410

1426

1684

1995

2057

2145

FUEL TANK CAPACITY L

209

340

RUNNING TIME at 75% / 100% PRP h

20,4 / 15,3

16,3 / 12,2

20,9 / 15,4

15,8 / 12,0

12,6 / 9,5

10,1 / 7,7

NOISE PRESSURE LEVEL at 7 mt dB(A)

GUARANTEED SOUND POWER LEVEL LWA dB(A)

STATIONARY RANGE / SOUNDPROOF VERSION

gsw series

POWERFUL

GENERATION

Heavy duty generators developed with latest technology engines and

next-generation electronic devices become a product capable to obtain

the maximum performance within the minimum delay, and the highest

reliability with the lowest exhaust emissions.

Cylinder head

LTS - Load Transfer Switch (motorized)

GENERATING SET

GSW310m

GSW330m

GSW405m

GSW440m

GSW515m

GSW570m

GSW665m

GSW730m

Standby Power LTP kW/kVA

247,6/309,5

264,0/330,0

325,8/407,2

349,6/437,0

406,6/508,2

450,3/562,9

527,1/658,9

581,8/727,3

Prime Power prp kW/kVA

224,2/280,2

247,6/309,4

294,5/368,2

325,8/407,2

368,1/460,1

407,9/509,9

478,1/597,6

527,1/658,9

VOLTAGE Volt / Frequency Hz

400/50

Phases

ENGINE

Brand

MTU

Model

6R1600G70F

6R1600G80F

8V1600G70F

8V1600G80F

10V1600G70F

10V1600G80F

12V1600G70F

12V1600G80F

Cooling System

Water

Fuel

Diesel

Number and disposition of cylinders

6 in line

8 V angle

10 V angle

12 V angle

Displacement cc

10500

14000

17500

21000

Aspiration

Turbocharged intercooler

Starting system / Electric circuit (Volt)

Electric / 24

Speed rpm

1500

Speed governor

Electronic

Stand by Power LTP kW

264

291

348

384

433

478

559

617

Prime Power PRP kW

239

264

315

348

392

433

507

559

Fuel consumption at 75% / 100% PRP L/h

44,7/58,1

48,6/63,6

63,4/81,3

62,1/82,7

78,4/109,5

76,5/105,1

98,1/131,6

106,0/142,6

ALTERNATOR

Type

Brushless

Poles

VOLTAGE regulation system

Electronic

OVERALL DIMENSIONs AND WEIGHT

Length mm

3950

4180

4700

Width mm

1460

1800

1670

Height mm

2175

2160

2430

weight Kg

3740

4660

5400

5520

5895

6100

Fuel tank capacity L

636

Running time at 75% / 100% PRP h

14,2/10,9

13,1/10,0

10,0/7,8

10,2/7,7

8,1/5,8

8,3/6,1

6,5/4,8

6,0/4,5

Noise Pressure level at 7mt dB(A)

Guaranteed sound power level LWA dB(A)

105

STATIONARY RANGE

gSw HIGHER POWER series

MORE POWER IN TIME

These generators are designed to fulfill the increase

of energy demand with high quality products for

every kind of application, but at the same time

to enjoy the economic/delivery benefits of a standard

production.

GENERATING SET

GSW815p

GSW875p

GSW1130p

GSW1400p

GSW1510p

STAND BY POWER LTP kW/kVA

660,9 / 826,2

699,0 / 874,0

917,8 / 1147,2

1119,0 / 1399,0

1209,9 / 1512,4

PRIME POWER PRP kW/kVA

601,0 / 751,3

646,0 / 807,0

835,4 / 1044,2

1013,0 / 1266,0

1100,7 / 1375,9

NOMINAL VOLTAGE Volt / FREQUENCY Hz

400 / 50

PHASES

ENGINE

BRAND

Perkins

MODEL

4006-23 TAG2A

4006-23 TAG3A

4008TAG2A

4012-46TWG2A

4012-46TWG3A

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 24

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

6 in line

8 in line

12 V angle

TOTAL DISPLACEMENT cc

22921

30561

45842

AIR INTAKE

Turbocharged Intercooler

Turbocharged CAC

SPEED rpm

1500

SPEED GOVERNOR

Electronic

STAND BY POWER LTP kW

695

760

958

1166

1263

PRIME POWER PRP kW

632

679

872

1055

1149

FUEL CONSUMPTION at 75% / 100% PRP L/h

125 / 164

134 / 176

163 / 223

214 / 278

230 / 301

ALTERNATOR

TYPE

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

LENGTH (OPEN SET - SOUNDPROOF) mm

4100 - 6541

4830 - 7900

4800 - 8500

WIDTH (OPEN SET - SOUNDPROOF) mm

2130 - 2171

2050 - 2470

HEIGHT (OPEN SET - SOUNDPROOF) mm

2218 - 2679

2460 - 2950

2460 - 2990

2660 - 2990

WEIGHT (OPEN SET - SOUNDPROOF) Kg

6200 - 8460

6210 - 8460

8170 - 10110

10290 - 12150

10290 - 13260

FUEL TANK CAPACITY L

1000

RUNNING TIME at 75%/100% PRP h

8,0 / 6,1

7,5 / 5,7

6,1 / 4,5

4,7 / 3,6

4,3 / 3,3

NOISE PRESSURE LEVEL at 7 mt dB(A)

- / 70

STATIONARY RANGE

GENERATING SET

GSW1650p

GSW1780p

GSW2025p

GSW2266p

GSW2520p

STAND BY POWER LTP kW/kVA

1296,0 / 1620,0

1424,0 / 1780,0

1636,4 / 2045,5

1814,0 / 2268,0

2016,0 / 2520,0

PRIME POWER PRP kW/kVA

1240,0 / 1550,0

1360,0 / 1700,0

1514,7 / 1893,4

1617,1 / 2021,4

1815,0 / 2269,0

NOMINAL VOLTAGE Volt / FREQUENCY Hz

400 / 50

PHASES

ENGINE

BRAND

Perkins

MODEL

4012-46TAG2A

4012-46TAG3A

4016-61TRG1

4016-61TRG2

4016-61TRG3

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 24

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

12 V angle

16 V angle

TOTAL DISPLACEMENT cc

45842

61123

AIR INTAKE

Turbocharged CAC

SPEED rpm

1500

SPEED GOVERNOR

Electronic

STAND BY POWER LTP kW

1417

1579

1694

1885

2083

PRIME POWER PRP kW

1289

1436

1568

1674

1875

FUEL CONSUMPTION at 75% / 100% PRP L/h

241 / 317

275 / 366

312 / 394

332 / 433

358 / 482

ALTERNATOR

TYPE

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

LENGTH (OPEN SET - SOUNDPROOF) mm

4970 - 8500

5620 - 12190

WIDTH (OPEN SET - SOUNDPROOF) mm

2050 - 2470

2200 - 2438

2280 - 2438

HEIGHT (OPEN SET - SOUNDPROOF) mm

2660 - 2990

2960 - 2896

3520 - 2896

WEIGHT (OPEN SET - SOUNDPROOF) Kg

11320 - 13560

14140 - TBD

14588 - TBD

14902 - TBD

14910 - TBD

FUEL TANK CAPACITY L

1000

RUNNING TIME at 75%/100% PRP h

4,2 / 3,2

3,2 / 2,5

3,4 / 2,6

3,0 / 2,3

2,8 / 2,1

NOISE PRESSURE LEVEL at 7 mt dB(A)

- / 70

- / on request

STATIONARY RANGE

gSw HIGHER POWER series

MORE POWER IN TIME

These generators are designed to fulfill the increase of energy demand with high quality products

for every kind of application, but at the same time to enjoy the economic/delivery benefits of a standard production.

GENERATING SET

GSW870m

GSW1000m

GSW1120m

GSW1260m

GSW1500M

STAND BY POWER LTP kW/kVA

697,0 / 871,0

808,0 / 1010,0

895,7 / 1119,7

1009,9 / 1262,4

1216,0 / 1520,0

PRIME POWER PRP kW/kVA

631,0 / 788,0

731,0 / 913,0

810,0 / 1013,0

913,9 / 1142,4

1176,0 / 1470,0

NOMINAL VOLTAGE Volt / FREQUENCY Hz

400 / 50

PHASES

ENGINE

BRAND

Mtu

MTU

MODEL

12V2000G65

16V2000G25

16V2000G65

18V2000G65

12V4000G23R

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 24

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

12 V angle

16 V angle

18 V angle

12 V angle

TOTAL DISPLACEMENT cc

23880

31840

35820

57199

AIR INTAKE

Turbocharged intercooler

SPEED rpm

1500

SPEED GOVERNOR

Electronic

STAND BY POWER LTP kW

733

935

1052

1285

PRIME POWER PRP kW

663

633

846

952

1165

FUEL CONSUMPTION at 75% / 100% PRP L/h

128 / 167

145 / 191

158 / 210

211 / 272

223 / 285

ALTERNATOR

TYPE

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

LENGTH (OPEN SET - SOUNDPROOF) mm

4100 - 6541

4226 - 6541

4720 - 8500

5300 - 12190

WIDTH (OPEN SET - SOUNDPROOF) mm

2130 - 2171

1900 - 2470

2000 - 2438

HEIGHT (OPEN SET - SOUNDPROOF) mm

2294 - 2679

2295 - 2679

2560 - 2990

2500 - 2896

WEIGHT (OPEN SET - SOUNDPROOF) Kg

6200 - 8460

6950 - 9810

7150 - 10020

7840 - 10820

11590 - TBD

FUEL TANK CAPACITY L

1000

RUNNING TIME at 75%/100% PRP h

7,8 / 6,0

6,9 / 5,2

6,3 / 4,8

4,7 / 3,7

4,5 / 3,5

NOISE PRESSURE LEVEL at 7 mt dB(A)

- / 75

(*) Dimensions and weights without radiator

STATIONARY RANGE

GENERATING SET

GSW1770M

GSW2040M

GSW2270M

GSW2600M

STAND BY POWER LTP kW/kVA

1424,0 / 1780,0

1635,4 / 2044,3

1814,0 / 2268,0

2044,4 / 2555,5

PRIME POWER PRP kW/kVA

1328,9 / 1661,2

1482,8 / 1835,5

1689,0 / 2111,0

1853,7 / 2317,2

NOMINAL VOLTAGE Volt / FREQUENCY Hz

400 / 50

PHASES

ENGINE

BRAND

MTU

MODEL

12V4000G23

12V4000G63

16V4000G23

16V4000G63

STARTING SYSTEM / ELECTRIC CIRCUIT (Volt)

Electric / 24

FUEL

Diesel

NUMBER AND DISPOSITION OF CYLINDERS

12 V angle

16 V angle

TOTAL DISPLACEMENT cc

57199

57200

76300

AIR INTAKE

Turbocharged intercooler

SPEED rpm

1500

SPEED GOVERNOR

Electronic

STAND BY POWER LTP kW

1522

1693

1928

2112

PRIME POWER PRP kW

1380

1535

1748

1915

FUEL CONSUMPTION at 75% / 100% PRP L/h

249 / 320

275 / 362

315 / 411

341 / 447

ALTERNATOR

TYPE

Brushless

POLES

VOLTAGE REGULATION SYSTEM

Electronic

OVERALL DIMENSIONS AND WEIGHT

LENGTH (OPEN SET - SOUNDPROOF) mm

5300 - 12190

6100 - 12190

WIDTH (OPEN SET - SOUNDPROOF) mm

2000 - 2438

2300 - 2438

HEIGHT (OPEN SET - SOUNDPROOF) mm

2500 - 2896

2790 - 2896

WEIGHT (OPEN SET - SOUNDPROOF) Kg

12150 - TBD

12430 - TBD

15620 - TBD

15900 - TBD

FUEL TANK CAPACITY L

1000

RUNNING TIME at 75%/100% PRP h

4,0 / 3,1

3,6 / 2,8

3,2 / 2,4

2,9 / 2,2

NOISE PRESSURE LEVEL at 7 mt dB(A)

- / 75

STATIONARY RANGE / CUSTOMIZED SOLUTIONS

gcw UNITS

TURNKEY INSTALLATIONS

The GCW units are customized generators specially developed and produced

to meet specific customer requests.

All generators are produced in either standard or customized configuration,

according to the customer’s requirements.

Each machine is also designed to meet the installation requirements.

Listed below are some of these projects.

Turnkey installations

Our specialised staff is able to study and offer turnkey projects for all proposed machines,

and to cooperate with the development of the complete project, depending on the agreed

technical specifications and terms of reference.

Control Panels

All the machines can be equipped with manual MCP, automatic ACP or AMF control panels,

as well as parallel panels between two or more generators and parallel with the mains.

Other options can be studied by our Technical Office.

Soundproof Canopies and Containers

The generators can be fitted with soundproof canopies or certified containers

with high quality finishes and appearance, to satisfy all requirements.

Soundproof versions can be equipped with internal lighting systems (standard in containers),

for easy and safe maintenance.

Additional electric sockets are also available to allow use of external tools.

Berlin Telecommunication project

Customized generating set with very low noise level. The machine has a

power of 2000 kVA and is placed inside a special canopy 75 dB(A) at 1 m.

The total height of the canopy is around 7 meters and it is equipped with

motorized louvers, fire detector system.

The engine has redundant electric starting system (double electric engine,

double battery pack, double battery charger) and the

alternator is double bearing with thermistors.

Formentera ENDESA project

PRAMAC has been, once more, the company selected by ENDESA to

supply 8MW during summer period, in order to help the main grid in

Formentera Island, next to Ibiza, needed to secure all the

electricity required by the high number of tourists.

The seven PRAMAC generators were installed using paralleling

synchronization with main grid connection.

The main characteristics of this project:

- simple composition of seven units generating sets of prime power each 1.720 Kva;

- simple transportation and installation;

- high soundproof level in a 40 feet container each;

- low pollution level;

- simple synchronization operation;

- low fuel consumptions.

The plant was a turnkey project which included also electrical

connections, fuel pipe connections and external storage tank.

STATIONARY RANGE / CUSTOMIZED SOLUTIONS

CUSTOMIZED REFERENCE PROJECTS

Qatar MotoGP circuit

The photo of Qatar MotoGP World Championship by night made the world tour. The

leading role was played by 44 PRAMAC generators with a total capacity of around 11MW.

Each generator, provided with sand trap air filters, supplied 315 kVA power.

The material supplied by our company has sustained a spotlight system which covered

the area of 70 regular football fields, with an amount of power that could illuminate an

imaginary street from the capital of Qatar, Doha, to Moscow in Russia. Impressive

numbers and distances!

Formula 1 circuit

During 2008/2009 our generators were fully involved in the

formula 1 World Championship, since Abu Dhabi and Singapore Grand

Prix were fully supported by Pramac generators.

GSW generators, installed all along the circuit, operating in parallel

mode and running independently of the mains electric system were

providing the needed power. Total capacity of the machines up to

9.7MW. In particular, the 2008 Formula 1 SingTel Singapore Grand

Prix was the first ever Formula One race held at night under an

impressive floodlight system, supported by 24 Pramac generators.

ACCESSORIES & OPTIONALS

PORTABLE GENSETS

STANDARD

Magneto Thermal protection (S12000, SP and P)

Engine over temperature protection (P11000 Diesel, P6000s)

Oil guard system

Differential protection (P series, S series diesel)

Automatic Voltage Regulation AVR (SP series and P9000)

Isometer (P11000 diesel, P12000 diesel, SP series)

Voltmeter (P series, SP12000, and S series diesel)

Battery charger (S series, except S12000)

Hour Meter (SP series , S diesel and P)

Lifting Kit/ Hook (P series except P4500)

Double positive welding sockets - with additional resistance (W series)

Connector for AMF/RSS (S and P series)

OPTIONALS

Differential protection and hour meter (E and ES series)

Transportation kit (E, ES, S, W and P series, except P12000 diesel that is included)

Differential protection (S series*)

Isometer (S and P series)

Automatic Voltage Regulation AVR (ES, S and P series)

Automatic Mains Failure (AMF) (Available for generators with connector CONN of S and P series, not compatible with IPP)

Remote Control RSS (Available for generators with connector CONN of S and P series, not compatible with IPP)

Lifting Kit/ Hook (S series Gasoline - SP series)

Cover for portable generators. Dimensions (L x W x H): 80 x 58 x 57 cm.

Welding kit (W)

Inlet/Outlet pipe for motorpumps

*Included Voltmeter, hour meter and frequency meter

ACCESSORIES & OPTIONALS

STATIONARY GENSETS

STANDARD

Load transfer switch panels (LTS)

Single phase version (under request)

Electronic engine governor (not available on GBA and GBW series)

Preheating system (only on ACP panels)

Automatic fuel transfer pump (not available on GB series)

Remote Genset controlling via PC/modem/GSM (only on GS series Automatic range)

RS 485/Ethernet communication port (all GS automatic range)

Manual analogical full option panel (all GS range below GSW220)

Different canopy colour (under request)

Adjustable differential intensity (GS)

Residential silencer (soundproof models)

ACCESSORIES (SOUNDPROOF MODELS)

Socket kits

Rental kit (only on GS series below GSW275V)

Fully bunded baseframe

Site and road trailer (all range below GSW275V)

Galvanized skid baseframe (GS Series up to GSW220)

Hydraulic Lighting Tower (for GSW 10-45 and GSL 22-42)

OPTIONALS*

Extended capacity on base fuel tank

Automatic refueling system

Coolant pre-heating system

Differential protection

Residential silencer (Open set models)

IV poles circuit breaker instead of III poles

Exhaust compensator bellow

* depending on models

ELECTRICAL EQUIPMENT - MANUAL CONTROL PANELS

EQUIPMENT

ENGINE PROTECTION UNIT

□

●

1-Manual Analogue (Optional)

DC DISCONNECTION DEVICE

●

GBA 7/12/17L Open set

STARTING

Key

MAINS VOLTAGE

GENSET VOLTAGE (3 PHASES SENSING)

●

GENSET VOLTAGE (1 PHASE SENSING)

●

GENSET INTENSITY (3 PHASES SENSING)

●

GENSET INTENSITY (1 PHASE SENSING)

●

FREQUENCY METER

●

HOURMETER

●

2-Manual Analogue

BATTERY VOLTAGE AND INTENSITY

● (Only voltage)

GBW 10/22y-p

SPEED

●

GBW 30/45Y-p Open set

POWER (KVA, KW, KVAr, cosф)

- (Only kVA)

FUEL LEVEL

●

ENGINE TERMPERATURE

●

● (Not available on GSA42/65)

OIL PRESSURE INDICATOR

●

- (Standard from GSW220)

ALARMS & SHUTDOWNS

GENERATOR VOLTAGE OUT OF LIMITS

△

OVER-LOAD

△

BATTERY CHARGER ALTERNATOR FAILURE

● (Shutdown optional)

△

3-Manual Analogue

BATTERY VOLTAGE OUT OF LIMITS

●

GSW 10/22p-y Soundproof

GSL 30/42d Soundproof

FREQUENCY OUT OF LIMITS

△

GSW 30/45y-p Soundproof

LOW FUEL LEVEL

△

LOW OIL PRESSURE

● (Shutdown optional)

△

HIGH ENGINE TEMPERATURE

△

LOW COOLANT LEVEL

△ (On GSW80/150/220)

FAIL TO START

●

EXTERNAL SHUTDOWN

△

●

PROTECTION DEVICES

III POLES CIRCUIT BREAKER

●

4-Manual analogue

IV POLES CIRCUIT BREAKER

□

GSL 65d Soundproof

GSW 65/80/110/145/170/220I Soundproof

DIFFERENTIAL PROTECTION

●

GSW 65/80/110/150/155/165/170/210p Soundproof

INSULATION MONITORING

EMERGENCY STOP BUTTON

□

●

OTHER FEATURES

ACUSTIC ALARM

PHASE DETECTOR

BATTERY CHARGER

CANBUS COMMUNICATION

RS232 COMMUNICATION PORT

GSM communication device

RS485 / Ethernet communication port

5-MANUAL ANALOGUE FULL OPTION

EXTERNAL TERMINAL BOARD FOR LOAD CONNECTION

□

(UNDER REQUEST)

TERMINALS FOR AN EXTERNAL PANEL CONNECTION (LTS)

GSA/GSL/GSW all range up to 220 Open set and Soundproof

TERMINAL LOW POTENTIAL RELAY CARD

EXTERNAL START/STOP CAPABILITY

□

□ (Not available on GSW15-22)

□

□ (Not available on GSW15-22)

□

BATTERY CHARGER OUTPUT

TERMINALS FOR GENSET CUBICLE CONNECTION

CONTACTORS WITH INTERLOCK

5 METERS CONTROL WIRING

SOCKETS

Schucko socket

1 x Schuko 230V

□

□ (Only Soundproof sets)

6-Manual digital

Single phase CEE socket

1 x 230V 2P+T CE.

2 x 230V 2P+T CE.

□

□ (Only Soundproof sets)

GSA 22/30/42/65d Open set

GSL 30/42d Open set

Three phase CEE socket

1 x 400V 3P+N+T CE.

2 x 400V 3P+N+T CE.

□

□ (Only Soundproof sets)

GSW 65/80/110/145/170/220I Open set

GSW 65/80/110p Open set

* Different versions available

● STANDARD EQUIPMENT

△ ALSO WITH SHUTDOWN PROTECTION

□ OPTIONAL EQUIPMENT

- NOT AVAILABLE

ELECTRICAL EQUIPMENT - automatic CONTROL PANELS

EQUIPMENT

ENGINE PROTECTION UNIT

●

7-AUTOMATIC DIGITAL

DC DISCONNECTION DEVICE

●

GBW 10/22y-p

GBW 30/45y-p Open set

STARTING

Pushbutton

MAINS VOLTAGE

●

GENSET VOLTAGE (3 PHASES SENSING)

●

GENSET VOLTAGE (1 PHASE SENSING)

●

GENSET INTENSITY (3 PHASES SENSING)

●

GENSET INTENSITY (1 PHASE SENSING)

●

FREQUENCY METER

●

8-AUTOMATIC DIGITAL

HOURMETER

●

GSW 10/22p-y Soundproof

BATTERY VOLTAGE AND INTENSITY

●

GSL 30/42d Open set and Soundproof

SPEED

●

GSW 30/45y-p Soundproof

POWER (KVA, KW, KVAr, cosф)

●

FUEL LEVEL

●

● (Not available on GB)

●

ENGINE TERMPERATURE

● (Only GSL)

● (Only deutz, not on GSA42/65)

●

● (Only deutz, not on GB and on GSA42/65)

●

OIL PRESSURE INDICATOR

- (Standard fron GSW220)

●

- (Standard fron GSW220)

●

ALARMS & SHUTDOWNS

GENERATOR VOLTAGE OUT OF LIMITS

△

9-AUTOMATIC DIGITAL

OVER-LOAD

△

GSA 22/30/42/65d Open set

BATTERY CHARGER ALTERNATOR FAILURE

△

GSL 65 d Open set and Soundproof

GSW 65/80/110/145/170/220I

BATTERY VOLTAGE OUT OF LIMITS

●

Open set and Soundproof

FREQUENCY OUT OF LIMITS

△

GSW 65/80/110/150/155/165/170/210p

Open set and Soundproof

LOW FUEL LEVEL

△

△ (Not available on GB)

△

LOW OIL PRESSURE

△

HIGH ENGINE TEMPERATURE

△

LOW COOLANT LEVEL

△

△ (On GSW65/80/150/220)

△

△ (On GSW65/80/150/220)

△

FAIL TO START

●

EXTERNAL SHUTDOWN

●

PROTECTION DEVICES

10-AUTOMATIC DIGITAL

III POLES CIRCUIT BREAKER

●

GSW 275/330/415/450/510/560/590/630/705v

IV POLES CIRCUIT BREAKER

□

Open set and Soundproof

GSW 515/570/665/730m Open set and Soundproof

DIFFERENTIAL PROTECTION

●

INSULATION MONITORING

EMERGENCY STOP BUTTON

●

OTHER FEATURES

ACUSTIC ALARM

●

PHASE DETECTOR

●

BATTERY CHARGER

●

11-AMF DIGITAL

CANBUS COMMUNICATION

- (On GSW150/220 & Perkins from GSW110)

●

- (on GSW150/220)

●

GBA 7L/12L/17L / Open set

RS232 COMMUNICATION PORT

□

●

Portable generators (S and P series)

GSM communication device

□

RS485 / Ethernet communication port

□

EXTERNAL TERMINAL BOARD FOR LOAD CONNECTION

□

●

TERMINALS FOR AN EXTERNAL PANEL CONNECTION (LTS)

●

TERMINAL LOW POTENTIAL RELAY CARD

□

12-AMF DIGITAL

EXTERNAL START/STOP CAPABILITY

●

□

●

□

GBW/GSA/GSL/GSW all range up to 220

BATTERY CHARGER OUTPUT

Open set and Soundproof

TERMINALS FOR GENSET CUBICLE CONNECTION

●

CONTACTORS WITH INTERLOCK

●

5 METERS CONTROL WIRING

●

MOTORIZED CHANGEOVER < 160 Amp

●

SOCKETS

Schucko socket

□

□ (Only Soundproof sets)

13-LTS (LOAD TRANSFER SWITCH PANEL)

All ACP range

Single phase CEE socket

□

□ (Only Soundproof sets)

Three phase CEE socket

1 x 400V 3P+N+T CE. 1 x 400V 3P+N+T CE.

□

□ (Only Soundproof sets)

* Different versions available

● STANDARD EQUIPMENT

△ ALSO WITH SHUTDOWN PROTECTION

14-MPP PARALLEL PANEL

□ OPTIONAL EQUIPMENT

GSW all range from 110

- NOT AVAILABLE

ELECTRICAL EQUIPMENT

PRE-WIRED generating set without control panel

The generating set is supplied without control panel. All the controls and alarms coming from the engine and the

alternator are wired to a terminal board installed in a connection box, for an easy external control panel connection.

This is the ideal solution for markets and applications that require special controls.

MCP Manual Control Panel

The generating set is supplied with a manual control panel, mounted on the genset. The panel includes a manual control

unit (push button / key start type), main circuit breaker (three poles standard, four poles optional), differential protection

and all auxiliary controls and alarms. Power cables between generator and circuit breaker are included. There are

several different types of MCP panel available.

ACP Automatic Control Panel

The generating set is supplied with an automatic control panel, mounted on the genset. The panel includes an automatic

control unit that starts the genset in case of mains failure (it can be started manually too), main circuit breaker (three

poles standard, four poles optional depending on the model), differential protection and all auxiliary controls and alarms.

Power cables between generator and circuit breaker are included. All controls are wired to a plinth row installed in the

control panel for an easy external Load Transfer Switch (LTS) panel connection (this panel is optional).

AMF Automatic Mains Failure start control panel

This panel is built in a metal cabinet and supplied separate from the generator (free standing, for wall mounting). The panel

includes an automatic control unit that starts the genset in case of mains failure (it can be started manually too), two

change over contactors electrically and mechanically interlocked (for transferring the load between mains and generating set)

and all auxiliary controls and alarms. Five meters control cables are included.

All these controls and alarms are wired to a plinth row installed in the control panel for easy connection to the generator.

LTS Load Transfer Switch panel

This panel is built in a metal cabinet and supplied separated from the genset (free standing, for wall mounting). It is an

option of the ACP panel. The panel includes two change over contactors electrically and mechanically interlocked (for

transferring the load between mains and generating set) and all auxiliary controls. All these controls are wired to a

plinth row installed in the panel for an easy connection to the ACP panel (that is mounted on the genset). Five meters

control cables are included.

MPP Modular Parallel Panel

The generating set is supplied with an automatic control panel, mounted on the genset. The panel includes a digital control

unit (for monitoring, control, protection and load sharing for both single and multiple gen-sets operating in mains emergency or

parallel modes), main motorized Circuit Breaker (four poles) and all auxiliary controls and alarms. Power cables between generator and circuit

breaker are included. All controls are wired to an external multipin for an easy connection to additional generators or transference panels.

Depending on genset size additional genset equipment could be also necessary, please consult the factory.
